Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Specifications
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Model NO. :
Silicone Copper Harness
Conductor Material :
Copper
Sheath Material :
PVC
Insulation Material :
Silicone Rubber
Material Shape :
Round Wire
Range of Application :
Construction, Power Plant, Underground, Industrial
Brand :
Linke
Name :
Silicone Copper Harness
Core :
Multiple
Insulated Material :
Silicone
Size :
1-200mm
Temperature :
-60-200c
Voltage :
High Voltage
Usage :
Electrical Vehicle
Usage 1 :
New Energy Storage
Certification 1 :
UL
Type 1 :
25mm2 Silicone Cable
Type 2 :
50mm2 Silicone Cable
Type 3 :
75mm2 Silcone Cable
Type 4 :
95mm2 Silicone Cable
Type 5 :
120mm2 Silicone Cable
Transport Package :
Carton/Roll
Specification :
80*80*69CM
Trademark :
LINKE
Origin :
China
HS Code :
8544492900
Supply Ability :
50000m/day
Package Size :
80.00cm * 80.00cm * 69.00cm
Package Gross Weight :
250.000kg
Lead Time :
7-15days
Type :
Insulated
Conductor Type :
Twisted wire
Application :
Overhead, Heating, Underground, Construction, Power Plant, Underground, Industrial
Samples :
US$ 10/Meter 1 Meter(Min.Order) |
Customization :
Available
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Place of Origin :
Guangdong, China
Brand Name :
Linke
MOQ :
1000m
Price :
Negotiable
Packaging Details :
安全包装
Delivery Time :
7-15天
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
conductor material :
copper/Tinned Copper
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
colour :
customize
package :
By roll
Description


XLPE Silicone Rubber Harness for Electric Vehicle with UL TUV Manufacturer

Product Parameters
Type XLPE Silicone CABLE
Cable grade -40ºC~+180ºC600V AC/1000V DC
Standard LV 216-1/ISO 6722
Item SPEC mm²
(****)		 Conductor Insulated
Material Structure(mm) max twisted OD(mm) Material OD
(mm)		 mini thickness
(mm)		 Color 20ºC conductor resistance mΩ/m) 20ºC insulated cubic resistance rage
TEVB400-XX-275 4mm² Copper 56/(0.30±0.008) 2.80 Silicone 4.20±0.20 0.64 Orange(RAL2003) Or Other Color custom ≤4.70 >=10¹³Ω·mm
TEVB600-XX-545 6mm² 84/(0.30±0.008) 3.40 4.80±0.20 0.64 ≤3.10
TEVBA10-XX-198 10mm² 323/(0.20±0.008) 4.50 6.20±0.30 0.80 ≤1.82
TEVBA16-XX-246 16mm² 512/(0.20±0.008) 5.80 8.00±0.30 0.80 ≤1.16
TEVBA25-XX-191 25mm² 790/(0.20±0.008) 7.20 9.70±0.30 1.04 ≤0.743
TEVBA35-XX-273 35mm² 1090/(0.20±0.008) 8.50 10.65±0.35 1.04 ≤0.527
TEVBA50-XX-246 50mm² 1600/(0.20±0.008) 10.50 12.80±0.40 1.20 ≤0.368
TEVBA70-XX-275 70mm² 2175/(0.20±0.008) 12.50 14.70±0.40 1.20 ≤0.259
TEVBA95-XX-069 95mm² 3000/(0.20±0.008) 14.80 16.90±0.50 1.28 ≤0.196
TEVBA120-XX-058 120mm² 3700/(0.20±0.008) 16.50 19.00±0.50 1.28 ≤0.153




Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
Product Description

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles
Company Profile

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.

In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of

wire and cable. Linke provide various cables&custom cable solutions for all over the world.

We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,

towlobe cable, UL wire, automotive cable, etc.

At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-engineer approach to develop better cables for customers and improve the quality of one's life.

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles

Certifications

We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269

(Single conductor,thermoplastic insulation)

UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,

UL2587,UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664

ISO9001 and ISO13485,TS16949

CNR- Appliance Wiring Material,

Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.

Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.

Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles

Power Plant Application UL TUV for XLPE Silicone Rubber Harness in Electric Vehicles

FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.

Welcome to visit us. We'll pick you up in Shenzhen.

2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.

3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.

4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.

5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
