ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
ISO9001 10KW Wire Terminal Crimping Machine , Durable Wire Stripping Twisting Machine
Specifications
Brand Name :
LIN QUAN
Model Number :
LOONG-860
Certification :
ISO9001, CE
Place of Origin :
China
MOQ :
1
Price :
USD $ 66,000~500,000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 machine per month
Delivery Time :
1-3 Months
Packaging Details :
pearl wool+protective film+wooden box
Capacity :
1000pcs/hr
Power Source :
3phase 380v/50HZ
Color :
white and grey(customize acceptable)
Usage :
both end Cutting , Stripping , Crimping and inserting
Wire Cross-sections :
0.13 – 2.5 mm² (AWG 26 –14)
Power :
10KW
Connector Housing :
30 kinds of the Housing
Wire Changer :
Max. 36 wires(difference color)
Description

Usb Power Cord Harness Wire Automatic Coil Wire Winding Machine Fully Automatic

Technical Data

Function Cutting, stripping, both end crimping, both end inserting,adjusting height on touch screen, pull force inspection, discharging defective products while selecting
Crimping Capacity 2.5TON Servo motor six sets
(Can be expanded according to customer products)
Wire Cross-sections 0.13 – 2.5 mm² (AWG 26 –14)
Feeding Wire Length 0-9999mm
Strip Length Full strip 15mm, half strip 15mm
Wire Changer Max. 36 wires(difference color)
Wire End Storage Rotary storage unit with a maximum of 30 storage spaces
Process Monitoring (integrated) CCD Terminal Detection
Crimping Force Monitoring
Insertion Force Monitoring
Capacity 2.5 sec per single-sided loading
(Piece output is dependent on wire length and housing/terminal combinations)
Block Feed Linear-carrier housing transferring/ Plate-loop conveying housing feeding module
(According to customer requirements)
Connector Housing 30 kinds of the Housing
Electrical Connection 3 phase/220v/50HZ
Power 10KW
Compressed Air 0.5Map

The Loong Series Harness Manufacturing can produce more wire harnesses of varying degrees of complexity.

It has the functions of Both-end measuring cutting, Both-end striping, Both-end crimping, Both-end Insertion and so on. Reduce production time significantly.

3 or 12 modules can be selected, as required. The Loong Series is a better choice for miniaturization and increasingly smaller batches.

These machines make it possible to manufacture a range of different wire harnesses.
