ISO9001 Both End Terminal Insertion Machine , 220V Cable Cutting And Crimping Machine
ISO9001 Both End Terminal Insertion Machine , 220V Cable Cutting And Crimping Machine
Specifications
Brand Name :
LINQUAN
Model Number :
SLQ-60A
Certification :
ISO9001, CE
Place of Origin :
China
MOQ :
1
Price :
USD $66,000~500,000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 machine/month
Delivery Time :
1-3months
Packaging Details :
wooden box
warranty :
1 year
color :
white
power :
3.5KW
Drive Mode :
Mitsubishi SERVO Drive, IPC
Capacity :
Both-end crimping 3200pcs/H
Penetraction Depth :
MAX 3mm
Stripping Length :
1.0-15.0mm
Power Source :
Single-phase/220V/50Hz
Description

Five Wire Cutting Stripping Crimping Tinning Machine With Auto Feeding System Copper Wire Tinning Machine

Automatic Terminalboth end Crimping Machine(short and fine wire)

Equipment Configuration

With the German high pixel image detection system

Equipped with high precision(Japan THK),cylinder(SMC),motor(MITSUBISHI) sensor(OMRON)

Cutting Precision

It is based on a capacitive measuring principle, is integrated in the blade holder and can be operated using any standard stripping blade.
The sensitivity of the monitoring can be configured using setting parameters. Defective wire ends are detected automatically and rejected
Cutting length shorter than 100mm, error range 0.5mm+

Self-Developed Crimping Head
Pass CPA+ pressure stability test CMK can reach to 4.0 or higher,far higher than the industry standard 1.6(Detailed data reports can be provided)
Higher stability and accuracy
Adjust height on touchscreen

Equipment Function

1. Double camera shot visual inspetion

2. Discharge the defective and without crimping at A end

3. Pressure detection function at both A and B end

4. Discharge the defective ones and then fool-proof clipping

5. Adjust the crimping height on touchscreen

6. High speed, the maximum can reach 3200pcs/H

Technical Parmeters

Mechine Function Wire measuring cutting, Two ends(half striping, striping, pressing), Stripping length, Penetraction depth crimping sinking buffer structure, Terminal vertical delivery device pre-striping the whole line function
Capacity Both-end crimping 3200pcs/H
Drive Mode Mitsubishi SERVO Drive, IPC
Wire Size AWG30-AWG14
Mould Assembly Type Assemble AS40, AS42, AE30( Customized Acceptable)
Wire Cutting Length 30-9999mm
Cutting Precision ±0.5mm
Stripping Length 1.0-15.0mm
Penetraction Depth MAX 3mm
Crimping Capacity 2 TON servo motor two sets mute specifications
Detection Device Air pressure decline, Wire exists or not, Wire overload, Terminal exists or not, Terminal overload, Stripping images detection, Terminal images detection, Pressure detection
Power Source Single-phase/220V/50Hz
Power 3KW
Compressed Air 0.5Mpa about 140NL/Min
Equipment Size L1510*W980*H1780mm
Weight 600KG
