Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness
Specifications
Brand Name :
LINQUAN
Model Number :
LOONG-850
Certification :
ISO9001, CE
Place of Origin :
China
MOQ :
1 set
Price :
USD 66,000 ~ 500,000 per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 machine/month
Delivery Time :
1-3 months
Packaging Details :
wooden box
Wire Size :
0.13mm²—4.0mm²(AWG26-14)
Warranty :
One year
Power :
7.5KW
Drive Mode :
PLC
Stripping Depth :
Maximum 3mm
Compressed Air Connection :
0.5Mpa
Cutting Precision :
Cutting length*0.02mm
Description

Fully Automatic Wire Harness Terminal Crimping Machine For Low Voltage Wire Harness

Equipment Configuration

With the German high pixel image detection system.

Industrialrobot(EPSON),Module(THK),Electric(YASKAWA),Cylinder(SMC),Sensor(Omron),CCD Camera(Germany Basler),Reducer(Xinbao).

The maximum speed can reach to 1200pcs/hr.

Equipment Function

It can process 6 different specifications and colors of wire and the amount of pin is unlimited.

The whole machine has the function of twisting wire and sticking tin (tinning).

Simultaneous multiple housing insertion.

Product Feature


1. The core parts of the equipment are all imported from Japan, which is for meeting the accuracy, speed and quality requirements.

2. Equipped with German high pixel image detection system, it can distinguish good and defective products by referring to qualified product image contour standard line, and place them separately through machine coordinated action to avoid customer complaints and losses caused by mixed defective products.

3. Equipped with pressure detection system. It can automatically generate terminal tension pressure curve analysis diagram, and automatically screen out defective products according to standard line, which not only increases the qualified rate of products, but also reduces labor cost.

Technical Parameters

Wire Size 0.13-4.0mm2
Mould Assembly Type Assemble AS40, AS42, AE30( Customized Acceptable)
Wire Cutting Length 60-9999mm
Penetraction Depth Maximum 3mm
Crimping Capacity 3 TON presser
Power Source China - 380V / 3 Phase / 50 Hz
Canada - 600V / 3 Phase / 60 Hz
USA/Japan - 480V / 3 Phase / 60 Hz
Mexico/Honduras - 480V / 3 Phase / 60 Hz
Europe - 400V / 3 Phase / 50 Hz
Power 7.5KW
Compressed Air 0.5Mpa
Equipment Size L3020*W1550*H1900mm
Weight 1000KG
Stripping Length Full strip: 0-15mm
Half strip: 0-15mm
Cutting Precision Cutting length*0.02mm
QC Devices CCD inspection modules, Crimping Force Monitoring (Force sensor),Insertion/Pull-back Force Monitoring (Force sensor), Terminal crimped height measuring instrument, Terminal pull force measuring instrument
QC Contents Wire presence, Wire overload, Terminal presence, Terminal overload, Stripping and crimping visual monitoring, Crimping force monitoring, Insertion & pull-back force monitoring
Efficiency Single-end crimping and insertion about 1200pcs/hr (Depends on different producing process and the functional module quantity, productivity is different)
Function Pre-feeding, Wire feeding, Fixed length cutting, Stripping, Both-end crimping, Single-end insertion, Adjusting crimp height on HMI, Unloading defective products through CCD inspection
