HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
HC-AQ0336BS-S4 Mitsubishi HC Servo Electronic Drip-Proof Motor
Specifications
Brand Name :
Mitsubishi
Model Number :
HC-AQ0336BS-S4
Certification :
CE
Place of Origin :
Japan
MOQ :
1 pc
Price :
contact us
Payment Terms :
T/T , Paypal
Supply Ability :
10000
Delivery Time :
3-5 work days
Packaging Details :
New in original box
Type :
Servo electronic drip-proof motor
Phase :
Single-phase
Protect feature :
Drip-proof
Product name :
Mitsubishi HC servo motor
Description
Category: Industiral Servo Motor Model: HC-AQ0336BS-S4
Rated Output Power: 10W Rated Speed: 3000r/min
Series: HC-AQ Series Brand: Mitsubishi
High Light:

ac servo motor

,

electric servo motor

Mitsubishi Melservo 10W Motors HC-AQ0135D-S4 Industrial AC Servo Motor NEW in stock

Specifications
Description HC-AQ0336BS-S4
Rated Output 0.03KW
Rated Torque 0.287 (40.643)N · m (oz · in)
Rated Speed (*1) 3000 rpm
Maximum Speed 4500 rpm
nstantaneous Permissible Speed 5150 rpm
Rated Current (Maximum Current) 2.3 (7.4)
Accessory Encoder
Insulation Class Class B
Weight 0.25KG

Notes:

1.When the power supply voltage drops, we cannot guarantee the output and rated speed.
2.80% ED at low noise.
80% ED: Indicates the condition in which operation time at read torque accounts for 80% and the other no load time accounts for 20% in a single operation cycle.
3.When the servo motor is equipped with reduction gear or electromagnetic brake, refer to the corresponding outline dimension drawing. For the EN Standard and UL/cUL Standard compliant models, please contact Mitsubishi.
4.If the load inertia moment ratio exceeds the indicated value, please contact Mitsubishi.
5.When the equipment is to be used in places where it is subjected to oil and/or water, such as on machine field sites, optional features apply to the equipment.
6.Except for the shaft-through portion and connector end.
Cables

Motor Type Power/Encoder Cable Length Power/Encoder Cable Model Number
HC-AQ0135D or HC-AQ0135BD 2 Meter MR-JRCBL2M-H
HC-AQ0135D or HC-AQ0135BD 5 Meter MR-JRCBL5M-H
HC-AQ0135D or HC-AQ0135BD 10 Meter MR-JRCBL10M-H
HC-AQ0235D or HC-AQ0235BD 2 Meter MR-JRCBL2M-H
HC-AQ0235D or HC-AQ0235BD 5 Meter MR-JRCBL5M-H
HC-AQ0235D or HC-AQ0235BD 10 Meter MR-JRCBL10M-H
HC-AQ0335D or HC-AQ0335BD 2 Meter MR-JRCBL2M-H
HC-AQ0335D or HC-AQ0335BD 5 Meter MR-JRCBL5M-H
HC-AQ0335D or HC-AQ0335BD 10 Meter MR-JRCBL10M-H



Related Motors

HC-KF13
HC-KF13B
HC-KF13K
HC-KF13D
HC-KF13BK
HC-KF13G1
HC-KF13G2
HC-MF13
HC-MF13B
HC-MF13BD-S15
HC-MF13BG1-UE
HC-MF13D
HC-MF13D-S2

HC-MF23
HC-MF23BK
HC-MF23BK-UE
HC-MF23G1-UE
HC-MF23-S15
HC-MF23-UE
INSTALLTION of Protection from oil and water
(1) Next, the servo motor is not waterproof (IP44). Do not subject the servo motor to oil and water.
Especially for the HC-MF / HC-KF / HC-AQ / HC-KFS / HC-MFS and HA-FF series, do not subject the
shaft-through portion to oil.
(2) When the gear box is mounted horizontally, the oil level in the gear box should always be lower than
the oil seal lip on the servo motor shaft. If it is higher than the oil seal lip, oil will enter the servo motor, leading to a fault. The HC-MF / HC-KF / HC-AQ / HC-MFS and HC-KFS series servo motor is not equipped with an oil seal and cannot be used with the gear box as described above. Oil should be shut off on the gear box side.
(3) When installing the servo motor horizontally, face the power cable and encoder cable downward. When installing the servo motor vertically or obliquely, provide a trap for the cable.
(4) Do not use the servo motor with its cable soaked in oil or water. (Figure on the right)
(5) When the servo motor is to be installed with the shaft end at top, provide measures so that it is not
exposed to oil and water entering from the machine side, gear box, etc.
(6) If the servo motor is exposed to oil such as coolant, the sealant, packing, cable and others may be
affected depending on the oil type.
(7) In the environment where the servo motor is exposed to oil mist, oil, water, grease and/or like, the
servo motor of the standard specifications may not be usable. Contact us.
(8) In the case of the servo motor with oil seal, the oil seal may sound during operation. It poses no
