R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
R7D-BPA5L OMRON 50w Power Output Servo Driver Frequency Amplifier
Specifications
Brand Name :
OMRON
Model Number :
R7D-BPA5L
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
negotiable
Payment Terms :
T/T, , L/C
Supply Ability :
88
Delivery Time :
5-8DAYS
Packaging Details :
New in original box
Warranty :
12 Months
Condition :
100% Original
Package :
Original Package
Product name :
Servo driver frequency amplifier
Description
Brand: OMRON Model: R7D-BPA5L
Origin: China
High Light:

ewing machine servo motor

,

ac servo motor

OMRON R7D-BPA5L AC Servodriver , Pulse Train Inputs , Single-Phase 100 VAC , 50W

Servo Drive Specifications (R7D-BP)

General Specifications

Item Specifications
Ambient operating temperature
Ambient operating humidity		 0 to 55 °C, 90% max. (with no condensation)
Ambient storage temperature
Ambient storage humidity		 -20 to 65 °C, 90% max. (with no condensation)
Storage and operating atmosphere No corrosive gasses, no dust, no iron dust, no exposure to moisture or
cutting oil
Vibration resistance 10 to 60 Hz; acceleration: 5.9 m/s2 (0.6 G) max.
Impact resistance Acceleration of 19.6 m/s2 max. 3 times each in X, Y, and Z directions.
Insulation resistance Between power supply/power line terminals and frame ground: 0.5 MΩ.
min. (at 500 VDC)
Dielectric strength Between power supply/power line terminals and frame ground: 1,500
VAC for 1 min at 50/60 Hz
Between each control signal and frame ground: 500 VAC for 1 min
Altitude 1,000 m above sea level max. (860 hp min.)
Degree of protection Built into panel (IP10).
International
standards		 EC
Directives		 EMC Directive EN 55011 class A group 1
EN 61000-6-2
Low Voltage
Directive		 EN 50178
UL standards UL 508C
cUL standards cUL C22.2 No.14
Korean Radio Regulations
(KC)		 Certified

Note: 1. The above items reflect individual evaluation testing. The results may differ under compound conditions.
Note: 2. Always disconnect all connections to the Servo Drive before you perform insulation resistance tests on it. If you
perform an insulation resistance test while the Servo Drive is connected, the Servo Drive may be damaged.
Never perform dielectric strength tests on the Servo Drive. Failure to follow this precaution may result in
damaging internal elements.
Note: 3. Depending on the operating conditions, some Servo Drive parts will require maintenance.
Note: 4. The service life of the Servo Drive is 50,000 hours at an average ambient temperature of 40°C at 80% of the
rated torque (excluding axial-flow fan).

Characteristics

100 VAC specification

Item Servo Drive model
R7D-BPA5L R7D-BP01L R7D-BP02L
Continuous output current (rms) 1.0 A 1.6 A 2.5 A
Momentary maximum output current (rms) 3.3 A 5.1 A 7.5 A
Power supply capacity 0.16 KVA 0.25 KVA 0.42 KVA
Input power supply voltage (main circuit) Single-phase 100 to 115 VAC (85 to 127 V), 50/60 Hz
Input power supply current (rms) (main circuit) 1.4 A 2.2 A 3.7 A
Heat generated (main circuit) 12 W 16 W 22 W
Control method All-digital servo
Inverter method IGBT-driven PWM method
PWM frequency 12 kHz 6 kHz
Maximum response frequency (command pulses) Line drive: 500 kpps, Open collector: 200 kpps
Weight 0.35 kg 0.42 kg
Applicable motor capacity 50 W 100 W 200 W

Similar Model Products

Specifications Model
Single-phase 100 VAC 50 W R7D-BPA5L
100 W R7D-BP01L
200 W R7D-BP02L
Single-phase/three-phase 200 VAC 50 W R7D-BP01H
100 W
400 W R7D-BP04H
Single-phase 200 VAC 200 W R7D-BP02HH
Three-phase 200 VAC 200 W R7D-BP02H
