OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
Specifications
Brand Name :
OEM & ODM
Model Number :
OEM & ODM
Certification :
CE UN38.3 MSDS
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
10000per
Delivery Time :
samples: 8days, bulk order: 30days
Packaging Details :
According to Stardard Export Packing. Carton box, wooden box, wooden pallet
Weight :
46KG
Application :
Golf Carts, SUBMARINES, electric vehicles
Max discharge current :
400A 35S / 600A 3S
Discharge Current :
100A-200A
Cycle life :
6000 Cycles
Warranty :
5 Years
Compatible :
Golf Carts 48V Electric Golf Carts,YAMAHA,Club Car,EZGO,ICON...
Description

OEM ODM 36V 48V 72V Golf Cart Lithium LiFePO4 Battery Pack 100Ah 200Ah for Electric Golf Cart

Products Description

1. Safety Performance: safest Lithium Iron Phosphate battery, CE IEC UN38.3 MSDS approved, built-in Smart 200A BMS
2. Long Cycle Life: > 6000 times, 6-8 times life cycle compared to lead acid battery
3. Deep cycle, no memory effect, highly efficient
4. Compact size and lightweight: 1/2 size & weight of lead acid battery
5. Good performance at high temperature
6. Low self-discharge rate: < 3% month

Product Paramenters

Nominal voltage (36V)38.4V (48V)51.2V (48V)51.2V (72V)76.8V
Capacity (Ah) 105Ah 105Ah 160Ah 105Ah
Battery Energy 4032Wh 5376Wh 8192Wh 8064Wh
Self-discharge 25℃,≤3% per month 25℃,≤3% per month 25℃,≤3% per month 25℃,≤3% per month
Cycle life >6000 cycles >6000 cycles >6000 cycles >6000 cycles
Charge Mode CC/CV CC/CV CC/CV CC/CV
Max. Continuous Charge Current 100A 100A 100A 100A
Charge Cut-off Voltage 43.8V 58.4V 58.4V 87.6V
Max. Continuous Discharge Current 100A 200A 200A 100A
Max. Pulse Current 200A 10S / 400 5S 400A 35S / 600A 3S 400A 35S / 600A 3S 400A 35S / 600A 3S
Discharge Cut-off Voltage 30V 40V 40V 60V
Communication mode CAN/RS485 RS485/CAN RS485/CAN RS485/CAN
Storage temperature 0~45℃ 0~45℃ 0~45℃ 0~45℃
Working Environment 0℃ ~ +55℃(Charge) 0℃~+55℃(Charge) 0℃~+55℃(Charge) 0℃~+55℃(Charge)
-20℃~+65℃(Discharge) -20℃~+65℃(Discharge) -20℃~+65℃(Discharge) -20℃~+65℃(Discharge)
Water Dust Resistance IP67 IP67 IP67 IP67
Housing Material Metal case Metal case Metal case Metal case
Bluetooth 5.0 Yes Yes Yes yes
GPS Feature Optional Optional Optional optional
Display Screen Optional Optional Optional optional
OEM & ODM Optional Optional Optional optional
Dimension 425*318*252mm 500*318*230mm 573*369*270mm 800*310*270mm
Weight 83.78lbs.(38Kg) 99.21lbs.(45kg) 149.91lbs.(68kg) 198.00lbs.(78kg)
Compatible Electric Golf Carts,YAMAHA,Club Car,EZGO,ICON,Golf Trolley,Electric Utility Vehicle,Sightseeing Car,Hunting Car,Electric Truck, Electric Tractors

OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200AhOEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200AhOEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200AhOEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah

FAQ

Q: Can your company accept OEM and ODM order?

A: Yes, we can, we are a plant with more than 10 years OEM and ODM experience, many of our customers have made big success in their field.

Q: Will this battery work well on my power tool just as my original battery?

A: 100% Compatible with your power tool battery, it works well as your original power tool battery

Q: What are the main cells of your products?

A: We have imported batteries and domestic batteries, imported batteries mainly use imported batteries from Sony, Samsung and LG brands as our power tool batteries, with 100% high quality.

Q: Does your product have an after-sale guarantee? How long is the warranty?

A: All our products have passed relevant quality inspection and certification, can be exchanged within 15 days, and guaranteed for 12 months.

Q: What certifications have the products of your factory passed?

A: All our products have FCC, CE, ROHS certification, quality inspection report and MSDS, shipping inspection report.
