Specifications
Brand Name :
OEM & ODM
Model Number :
72V 6Ah
Certification :
CE UN38.3 MSDS
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
10000per
Delivery Time :
samples: 8days, bulk order: 30days
Packaging Details :
According to Stardard Export Packing. Carton box, wooden box, wooden pallet
Battery type :
Lithium battery
Nominal Voltage (V) :
72V
Nominal Capacity (Ah) :
6Ah
Dimension :
380*40*68mm
Cycle life :
>800 times
Cell type :
18650-2500mAh
Charging port :
3 pins
Discharge port :
2 pins
Description

Custom Capacity Lithium Batteries for Electric Bikes: 36V, 48V, and 72V
Introducing our versatile lithium battery packs for electric bikes, available in 36V, 48V, and 72V configurations:

Custom Capacities: Tailored to meet your specific energy needs, ensuring optimal performance for your e-bike.
PVC Housing: Durable and lightweight design for easy installation and protection against the elements.
Lithium Technology: Delivers improved safety, thermal stability, and a longer lifespan compared to traditional batteries.
Lightweight Design: Optimized for minimal added weight, enhancing your riding experience.
Low Maintenance: Engineered for hassle-free operation with minimal upkeep required.
These lithium battery packs are the perfect solution for powering your electric bike efficiently and reliably.

Overview
ELECTRICAL SPECIFICATIONS
Nominal Voltage
72V
Nominal Capacity
6Ah
Energy
432Wh
Series and Parallel Connection
20S2P
Resistance
≤40 mΩ
Efficiency
≥99%
Cycle Life
≥800 cycles @80%DOD
Self Discharge
<3% per Month
Connector
customized
Cable length
customized
MECHANICAL SPECIFICATIONS
Dimensions (L x W x H)
380*40*68mm
Net Weight
2.4kg
Chemistry
NCM
Cell Type
18650(3200mAh)
Case Material
PVC
CHARGE & DISCHARGE SPECIFICATIONS
Standard Charge Current
≤3A
Max Charge Current
≤5A
Continuous discharge current
≤ 13A
Pulse discharge current
≤40A
Over-discharge protection cut-off voltage
65V
Over-charge protection cut-off voltage
84V
TEMPERATURE SPECIFICATIONS
Discharge Temperature
-4 to 140 ºF (-20 to 60 ºC)
Charge Temperature
32 to 113 ºF (0 to 45 ºC)
Storage Temperature
77±3 ºF (25±3ºC)

FAQ

Q: What type of electric bike battery?

A: It is a Li-ion battery, Chemical is Li(NiCoMn)O2.

Q: What is the difference between a Li-ion battery,Ni-Mn battery and Lead acid battery?

A: E-bike Li-ion battery have longer cycle life,normal cycle life is 800-1000 times, and also with light weight,small size, No memory effect,Nontoxic, environmental friendly.

Q: What's the temperature range of charge and discharge?

A: Charge Temperature: 0 to 45°C and Discharge Temperature: -20 to 65°C

Q: What kind of cells are used on this electric bicycle battery?

A: Different capacities with different cells, we make the battery with original A grade Brand and high-quality domestic cells, all can be customized as your requests.

Q: Does your e-bike battery come with a charger?

A: All of our e-bike batteries come with charger.We have normal charger and fast charger. If you need fast charger please contact with us.

Q: Do your electric bike batteries come with BMS?

A: Yes, Our batteries all with SEIKO IC BMS, with stable performance.Which can protect the battery avoid short circuit,Overcharged,Over discharge and Over current.

Q: Can you provide OEM and ODM service?

A: Yes, We are a professional Electric Bike Battery manufacture with factory, which produce all kind of high quality E-bike lithium batteries as customers' requirements and designs, welcome to place OEM and ODM orders and visit our factory.
