304 316 SS Filter Housing Manufacturers For Water Pretreatment System
304 316 SS Filter Housing Manufacturers For Water Pretreatment System
Specifications
Brand Name :
SFFILTECH
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs per month
Delivery Time :
20-30 days
Packaging Details :
wooden case
Name :
SS filter 304 316 housing with PP filter cartridge for water pretreatment system
Material Of Bag: :
Polyester
Bag number: :
1,2, 3, 4, 5, 6, 7, 8, etc
Inlet, Outlet: :
Tri Clamp, Flange, Thread, DIN, etc
Operating pressure: :
6 bar
Surface finish: :
Mirror Polish, Sand blasting
Description

SS filter 304 316 housing with PP filter cartridge for water pretreatment system

Bag filters are particularly useful for filtering large volumes or high viscosity liquids, which are constructed of filter housing, filter bags, internal cage to support bags, positive sealing arrangement.

Features & Benefits:

  • High flow rates
  • Complete stainless steel 304,316L structure
  • High temperature & High pressure design are available
  • Wide range of bag size for choice
  • Easy to clean

Bag Size:

Item Flow rate(m3/h) Filtration area(m2) Diameter(mm) X Length(mm)
#1 20 0.25 180(7") X 410(16")
#2 40 0.50 180(7") X 810(32")
#3 6 0.10 102(4") X 210(8.25")
#4 12 0.15 102(4") X 356(14")
#5 25 0.30 175(6,7/8") X 870(34")
*Size could be on your request

Specifications:

Type Model Dimension(mm) Connection Bag Flow rate(m3/h)
Diameter Height Size Q'ty(pc)
Single Bag Filters BJD1 220 550 2''Tri-Clamp, Flange, NPT, DIN, etc #1 One 20
BJD2 220 950 #2 40
BJD3 130 650 #3 6
Muti-Bag Filters BJD2-2 400 1550 3'', 4", 5" Tri-Clamp, Flange, NPT, DIN, etc #2 Two 80
BJD2-3 500 1550 #2 Three 120
BJD2-4 550 1550 #2 Four 160
BJD2-5 600 1550 #2 Five 200

Operating Conditions(Bag Filter):

Max.Operating Pressure: 6 bar(87psi) , 10.34bar(150psi)

Max.Operating Temperature: 120°C

Applications:

Processing Chemicals Paints,Inks,Coolants
Oils,Edible Oils, Vegetable Oils Pharmaceuticals
Sugar Syrup Cleaning Fluids
