Specifications
Brand Name :
Labelong
Model Number :
BL-600
Certification :
CE ISO
Place of Origin :
Jiangsu
MOQ :
One set
Price :
Negotiable
Payment Terms :
T/T. L/C
Supply Ability :
50-100SET/YEAR
Delivery Time :
30-60 working days
Packaging Details :
Wooden case
Model :
BL-600
Material :
sus304
Condition :
New
Working :
Automatic
Color :
Silver grey
Packaging Material :
Plastic
Quality :
TOP
Description

Labelong Easy Use Stretch Bottle Mold Blowing Machines Water Juice Bottle Blower Machine

Product Description
1.Utilization of automatic central lubrication.
2.Compact space design for convenience of mold-conversion,repairing and maintenance.
3.Minimized transfer pitch for increasing heating efficiency and saving energy.
4.Swift exchange design for preform mandrels.
5.Optimized air flow in the oven for stable heating process.
6.Easy to adjust,exchange and access heating oven;Protection for preform thread against heating.
7.Intact rotating robot grip with linear guider for right access,rapid motion;reducing adjustment and maintenance time.
8.Electronic inspector for ejecting faulty preform and bottles.
9.Fast,safe,and accurate cam-controlled blowing wheel for providing the best bottles.
10.Precise control of blowing technique to produce less-weighted bottle.
11.Smart design for quick conversion of blow mold.
12.Through finite element analysis to optimize modular design for reducing machine wearing and moving inertia.
13.Operating machine through touch panel; program protected by code lock
Features
A. Stable performance with advanced PLC.
B. Conveying preforms automatically with conveyor.
C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
D. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
E. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
F.No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
G. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
H. Strong clamping force with high pressure and double crank links to lock the mold.
I. Two ways of operating: automatic and manual.
J. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
K. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
L. Contamination is avoided for the bottle body.
M. Ideal effect of the chilling with the chilling system.
N. Easy installation and starting
O. Low rejection rate: less than 0.3percent.
Model QCS-C-1500 QCS-C-3000 QCS-C-1502
Production Capacity (BPH) 1500-2200 1200-1800 3000-4400
Bottle (product) Volume(ml) 1500 3000 1500
Max. Diameter (mm) 90 130 90
Max. Height (mm) 320 320 320
Mould Cavity 2 2 4
Thickness (mm) 140 180 140
Max. Width X Height (mm) 138X320 178X320 138X320
preform Max. Neck Size (mm) 20-35 20-40 20-35
Max. Length (mm) 120 120 120
Heating Area Lamp Quantity 8 8 18
Adjust Zone 1 1 2
Electrical Voltage Customized Customized Customized
Heating Power(KW) 16 16 32
General Power(KW) 17 17 34
Compressed Air Blow Compressed 3.0-4.0Mpa 3.0-4.0Mpa 3.0-4.0Mpa
Drive Compressed 0.8-1.0Mpa 0.8-1.0Mpa 0.8-1.0Mpa
Machine Dimensions Main Machine (mm) 2020X1200 X 1950 2070 X 1300 X1950 2600 X 2200 X 2000
Preform Auto-loader (mm) 2300 X 2300 X 3000 2300 X 2300 X 3000 2800 X1000 X3000
Machine Net Weight Main Machine (Kg) 830 930 1660
Preform Auto-loader (kg) 280 280 280
Machine Packaging Dimensions Main Machine (mm) 2320 X 1100 X 2150 2320 X 1500 X 2150 2400 X2250 X2150
Preform Auto-loader r(mm) 3100 X 1400 X 1700 3100 X 1400 X 1700 3100 X1400 X1700
Machine Gross Weight Main Machine (Kg) 950 1050 1900
Preform Auto-loader (kg) 510 510 510

Labelong Stretch Water Juice PET Bottle Blower Machine Silver Grey ColorLabelong Stretch Water Juice PET Bottle Blower Machine Silver Grey ColorLabelong Stretch Water Juice PET Bottle Blower Machine Silver Grey Color

Packaging & Shipping

Packing: Standard export wooden case confirmtion inan early date.

Delivery Time: 45days after confirming order detail delivery date should be decided according to production

season and order quantity.

Labelong Stretch Water Juice PET Bottle Blower Machine Silver Grey Color

Save

Company Information

Suzhou labelong packaging machinery co.LTD.

Labelong is a intergration of research and development, manufacturing, sales specialized automatic packagingmachinery manufacturers.

Company's main research and development production of various kinds of packaging machine ,As follow:

1.Water treament system

2.semi&full automatic blow molding machine

3.semi&full automatic bottling line

4.sleeve labeling machine

5.Adhesive labeling machine

6. hot melt glue labeling machine

7.packing machine

can be customized various non-standard machines.

The company has advanced international equipment and technology, the machine mainly components and circuit electric appliance all come

from Italy, Switzerland, Germany, Taiwan and France. our Company's products with high performance, high technology content products.

The products sell well all over the world, in part of models are exported to southeast Asia, the Middle East, Europe and the United States,

Malaysia and other countries and regions in the world...
Professional makes best quality, Labelong together with you to create success.
