800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
Specifications
Place of Origin :
Guangdong, China
Brand Name :
DJL
Certification :
ISO9001,CE
Packaging Details :
sea shippment package
Supply Ability :
100 Sets per Year
Price :
negotiable
Model Number :
DJL-QFL-1209C
MOQ :
1 set
Payment Terms :
T/T
Delivery Time :
45 work days
Applicable Industries :
Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms
Warranty of core components :
1 Year
Power :
12kw
Dimension(L*W*H) :
9000-1200mm
Weight :
6000kg
Cooling Capacity :
800-1000kgs/hour
Description

Liquid Nitrogen Tunnel Perch Fish Cooler Blast Freezer High Efficiency Iqf Freezing Machine

The tunnel refrigerator uses liquid nitrogen (Lin) as the refrigerant to directly freeze food. It has a variety of models and belt width. It is suitable for the industrial production mode of large batch, continuous, less humanization and large area of all kinds of food. It can be combined with other fresh food to form an automatic line.

Specification
<
Model Tunnel length Wire belt width Tunnel height Power freezing capacity
(mm) (mm) (mm) (KW) (kg/h)
DJL-QFL-1206 6000 1200 1750 10 400-600
DJL-QFL-1209 9000 1200 1750 12 800-1000
DJL-QFL-1212 12000 1200 1750 18 1000-1200
DJL-QFL-1609 9000 1600 1750 15 1000-1200
DJL-QFL-1612 12000 1600 1750 28 1800-2100
DJL-QFL-1618 18000 1600 1750 32 2000-2500
DJL-QFL-1815 15000 1800 1750 28 2000-2500
DJL-QFL-1818 18000 1800 1750 32 2200-2800
DJL-QFL-1824 24000 1800 1750 46 2800-3500

800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM

800KG/Hour 1000kgs/Hour Liquid Nitrogen Tunnel Freezer Quick Freezing Machine Ln2 OEM
Liquid nitrogen quick freezing system diagram
1. liquid nitrogen freezing tunnel
2. liquid nitrogen tank
3. tank base
4. exhaust duct
5. exhaust fan
6. liquid nitrogen pipeline
Equipment material:
SUS304 stainless steel
Working temperature:
-150℃~room temperature
Temperature control precision:
±2℃
Temperature uniformity:
±5℃
Cooling rate:
≥20℃/min
Heating rate:
≥5℃/min
Distribution specification:
380V/50HZ
Our Advantages
1. More than 10 years of professional recognition for ultra-low temperature deep cooling ,own independent intellectual property rights with more than 10 patented technologies.
2. The ability of compound innovation and multi-technology integration makes DJL unique in freezing machine industry.
3. Personalized scheme provides you the best cost performance of product
4. Close cooperative relationships with many universities
5. Three minutes quick-freezing ,the temperature low to minimum -196℃
6. Reasonable &exclusive quick-freezing total solution maximize utilize/save customers cost.
7. Free experiment and verification supporting .
8. Better serving customers by setting up branches and offices in country's areas.
FAQ

1. What certificate do you have?

Passed the ISO9001 Management System Certification in 2019.

2. How much liquid nitrogen will be consumed for freezing foods?

Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.

3. What is your warranty policy?

One year warranty, life-time maintenance.Components and parts are provided for free within warranty date for replacement.
