60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output
Specifications
Brand Name :
VLDL
Model Number :
VL6006L
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
12 pcs
Price :
Negotiable
Payment Terms :
T/T, Paypal
Supply Ability :
100000pcs/month
Delivery Time :
7-10 days
Packaging Details :
Carton, 12pcs / carton
Material :
Aluminum
Dimension :
170*90*50 MM
Net weight :
1.2 KG
Color :
Silver or Black
Applied to :
60V li-ion / LiFePO4 battery
Input volt :
Single 230V
Max Output :
73.5Vdc
Applied to EV :
Electric scooters / motorcycles
Charging method :
Automatic CC and CV
Warranty :
2 years
Description

Smart 60V 6A max 73.5V SLA battery charger for lead acid / AGM / GEL battery types

Features:
• Fully auto CC +CV(H)+CV(L) charging process,with MCU controller
• Constant big charging current for faster charging;
• automatically charging ending with Cut-Off output;
• Aluminum case with Fan Cooling
• It can charge any 60V SLA/VRLA/GEL/AGM battery with capacity 60-120Ah

Specification:
• Input: AC 180~264V 50/60Hz
• Output: DC 73.5V
• Charging current: 6A
• Dimensions (mm): 170*90*50mm
• Weight: 1.0kg

Quick Detail:
Brand Name:VLDL
Model Number: VL6006
Use: 60V Lead-Acid/AGM/GEL Battery
Type: Smart
Place of Origin:Guangzhou China (Mainland)
Battery charger: automatic battery charger 58.8V
Certificate: CE FCC ROHS
Color: Black/Silver
Shell Material:Aluminium alloy
Input voltage: AC180~264V 50/60Hz
Output voltage: 73.5V
Output current: 6A
Output power: 500W
Efficiency:>=85%
Shock & Vibration: SAEJ1378 Standard
Charge mode:CC---CV---Float Charge
Output Connector: Crocodile clip,aviation connector,XLR,Ring terminal,SB50A Plug,customization

Packaging & Delivery :
Inner package: white box/polybags/at your request

Outer package:carton
Delivery Detail:sample within 5 work days,7~15 days for bulk order

Specifications:
Portable fast SLA /AGM /VRLA /GEL charger 48V lead acid battery charger

Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection

LED Indicator:
• GREEN Light ON: fully charged or no connected.
• RED Light on: charging in process.

60V 6A Max 73.5V Sealed Lead Acid Battery Charger For AGM / GEL With Cut - Off Output

Output series: 240W Size: 170×90×50 mm Net weight: 1.0 KG
Input Model Apply to battery types Floating V CV (V) CC (A) Switching

AC Input:

230V

Frequency:

47~63HZ

 VL1220L 12V LiFePO4 Battery 14.6V 20A CC5~8%
VL1220 12V Lead-acid Battery 13.5V 14.7V 20A CC20%
VL2415LM 24V Li-MnO2 Battery 29.4V 15A CC5~8%
VL2415L 24V LiFePO4 Battery 29.2V 15A CC5~8%
VL2415 24V Lead-acid Battery 27.6V 29.4V 15A CC20%
VL3610LM 36V Li-MnO2 Battery 42V 10A CC5~8%
VL3610L 36V LiFePO4 Battery 43.8V 10A CC5~8%
VL3610 36V Lead-acid Battery 41.4V 44.1V 10A CC20%
VL4808LM 48V Li-MnO2 Battery 54.6V 8A CC5~8%
VL4808L 48V LiFePO4 Battery 43.8V 8A CC5~8%
VL4808 48V Lead-acid Battery 55.2V 58.8V 8A CC20%
VL6006L 60V LiFePO4 Battery 73V 6A CC5~8%
VL6006 60V Lead-acid Battery 67.5V 73.5V 6A CC20%
VL7205L 72V LiFePO4 Battery 87.6V 5A CC5~8%
VL7205 72V Lead-acid Battery 81V 88.2V 5A CC20%
Note: customized input / output / plug type / connectors are available.
