Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Lfp Lithium Ion Solar Battery
Specifications
Brand Name :
Winston
Model Number :
WB-LYP200AHA
Certification :
KC,UL.ROHS,MSDS
Place of Origin :
China
MOQ :
4PCS
Price :
USD259.99/pc
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/day
Delivery Time :
7-15 business days after recieving the payment
Packaging Details :
Normal export carton
Brand :
Winston
Battery type :
Lifepo4 battery
Warranty :
10years
Cycle life :
More than 5000 years
Size :
361mm x 55.2mm x256mm
Weight :
7.9kg+-200g
Certifications :
CE,Rohs,MSDS
Payment :
TT,DA,L/C
Description

Lithium battery 3.2v 100ah Winston Grade A with high performance

Winston Battery is rare -earth lithium yttrium power battery.

Winston Battery lithium Lifepo4 high power cells.-The Winston Batery products offer high power solutions for all kinds of litium cell applications.

200AH Winston Battery cell.

Modle:WB-LYP200AH

Norminal Capacity:200AH

Operating Voltage:2.8V-4.0V

Weight:7.9kg+-200g

Demensions: 361mm x 55.2mm x256mm

1. Product specifications

Item specification Remark
Product Model SP-LFP-200AHA(A)
Nominal Capacity 200Ah
Nominal Voltage 3.2V
Weight 5.8Kg±0.2Kg
Internal Impedance ≤0.4mΩ AC1kHz
Cycle Life ≥2000 Times 80%DOD
Self-discharge rate ≤5% 25ºC, 1 month
Dimension Height 280±1mm
Width 180±1mm
Thickness 69±0.5mm
Charge Standard Current 66A CC&CV
Max. Current 400A 2C
Limited Voltage 3.65V
Discharge Cut-off Current 6.7A 0.033C
Standard Current 66A
Max. Current 600A 3C
Cut-off Voltage 2.5V
Operating Temperature Charge 0ºC~45ºC
Discharge -20ºC~55ºC
Storage Temperature -10ºC~45ºC
Storage Humidity 25%~85% RH

2. Other Capacity Modles

Capacity Description Dimension(mm) Weight (kg) Inner resistance
40AH WB-LYP 40Ah 115×47×183 1.5 ≤0.7 mΩ
60AH WB-LYP60Ah 114×61×203 2.3 ≤0.55 mΩ
90AH WB-LYP90AHA-A 143×68×218 3 ≤0.5 mΩ
WB-LYP90AHA-B 143×61×218 3 ≤0.5 mΩ
100AH WB-LY100AHA-A 143×67×218 3.5 ≤0.45mΩ
WB-LY100AHA-B 179×62×218 3.5 ≤0.45mΩ
130AH WB-LYP130AHA 360x55x177 5.2 ≤0.45mΩ
160AH WB-LYP160AHA-A 182×70.5×277 5.6 ≤0.4 mΩ
WB-LYP160AHA-B 209×65×278 5.6 ≤0.4 mΩ
200AH WB-LYP200AHA-A 182×100×278 7.3 ≤0.35 mΩ
WB-LYP200AHA-B 361×55.2×256 7.3 ≤0.35 mΩ
260AH WB-LYP260Ah 361×55.5×283 8.7 ≤0.3 mΩ
300AH WB-LYP300Ah 362×55.5×306 9.7 ≤0.3 mΩ
400AH WB-LYP400AHA-A 449×70.5×282 13.5 ≤0.3 mΩ
WB-LYP400AHA-B 460×65×285 13.5 ≤0.3 mΩ
700AH WB-LYP700Ah 627×67×305 21 ≤0.3 mΩ
1000AH WB-LYP1000AHA-A 846×71×373 41 ≤0.3 mΩ
WB-LYP1000AHA-C 560×130×356 41 ≤0.3 mΩ

We have the capacity reach 40AH to 1000AH,You can choos the best one you need .If you dont know how to choose,just click "LIVE CHAT",

And we will service you ASAP.

3. Product Specification / Models

WB-LYP200AHA
4. Attention
1. Do not expose to, dispose of the battery in fire.
2. Do not put the battery in a charger or equipment with wrong terminals connected.
3. Avoid shorting the battery
4. Avoid excessive physical shock or vibration.
5. Do not disassemble or deform the battery.
6. Do not immerse in water.
7. Do not use the battery mixed with other different make, type, or model batteries.
8. Keep out of the reach of children.
5. Packing & Delivery
Packing:
1. Several batteries will be put inside a carton with pearl wool filled in.
2. If there are several cartons, it will be packed together on a pallet. The height of each pallet will not exceed 4 layers of cartons.
Delivery:

1. Transportation to USA:By sea+Express(DDP,Tax free)
ETD:5-8 days
ETA:25-35 days after sailing(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be update after pick up by local express.Usually it will take around 15-25 days after sailing.

2. Transportation to EU:By railway+Express(DDP,Tax free)
ETD:5-8 days
ETA:30-45 working days after sailing(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be update after pick up by local express.Usually it will take around 25-40 working days after sailing.

3. We can't deliver the following address directly:
USA: Military address and PO box address are not
acceptable; Puerto Rico, Virgin Islands, Guam, Alaska Note: Hawaii does not include customs duties and requires additional freight, Please contact us online.
Portugal: Azores and Madeira
Spain:Canary Islands, hueda and melilia
Russia: Kamchatka Peninsula
Other:Some remote areas not listed,Please provide shipping address and zip code to to us to check."

6. Company Profil

Changsha Deligreen power Co.,ld was established in 2010, which aims to provide the best product for people who are building their electric vehicles and who want real electric vehicles and power solutions for the storage energy project. With over 10 years of friendly cooperation with Winston Battery, CALB, CATL, Yinlong. Deligreen is an official leading dealer of Winston battery. Our facilities are located in Changsha, Hunan province, China. We have been serving our customers for almost 10 years and are here for the long term.

7. FAQ

Q1: What is your MOQ?
A1: Generally speaking, our MOQ is 50 pieces, which varies with different products.
Q2: Are these batteries brand new?
A1: Yes, all of these batteries we provide are brand new
Q3: Are the cells I bought balanced?
A3: we know the importance of maintaining the consistency of each cell in the battery pack, so we will match and balance all cells to ensure that the internal resistance, voltage, and capacity of cells are completely matched and balanced before delivery. This process is very necessary.
Q4:: I am a distributor. Can I cooperate with the battery warehouse for a long time?
A4: Yes, Individual pricing for large scale projects and wholesale demand is available
