Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh
Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh
Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh
Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh
Specifications
Certification :
CE, RoHS, MSDS, Un38.3
Brand Name :
RESKY
Model Number :
LP523450
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
Western Union,T/T
Supply Ability :
100000PCS/Day
Delivery Time :
7-10days
Packaging Details :
Paper box
Shape :
Square Battery
Electrolyte :
Li(Nicomn)O2
Rechargeable :
Chargeable
Nominal Capacity :
1000mAh
Weight :
9g
Connector :
Jst, Molex....
Color :
Blue PVC
Specification :
5.2*34*50mm
HS Code :
8507600090
Description
Product Description

Lithium polymer battery pack 523450 603450 3.7V 7.4v 1000mAh Power lipo batteries

NO. Items Specifications
1 batteries 7.4v 1000mah lipo battery
2 Charge voltage 8.4V
3 Nominal voltage 7.4V
4 Nominal capacity 1000mAh 0.2C Discharge
5 Charge current
 Standard Charging:0.5C
Rapid charge: 1.0C
6 Standard Charging method 0.5C CC(constant current)charge to 8.4V, then CV(constant voltage 8.4V)charge till charge current decline to ≤0.05C
7 Charging time
 Standard Charging:2.75hours(Ref.)
Rapid charge: 2hours(Ref.)
8 Max.charge current 1.0C
9 Max.discharge current 1.0C
10 Discharge cut-off voltage 2.5V0.25V(0.2C)
11 Operating temperature Charging: 0 °C ~45 °C
Discharging:0 °C ~45 °C
12 Storage temperature -10°C~ +45 °C
13 Dimension Length: 50±2mm (not including tabs)
Width: 34±0.5mm
Thickness:11±0.2mm
14 Drop Test The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage
15 cycle time ≥500times

What's the difference for lithium polymer battery and cylindrical battery?

Structure and Design:

Lithium Polymer Battery:

Shape and Flexibility: Lithium polymer batteries can be designed in various shapes, such as prismatic or even custom shapes, due to their flexible electrolyte and packaging materials.

Electrolyte: They use a gel-polymer electrolyte, which is a solidified liquid electrolyte embedded in a polymer matrix.

Cylindrical Battery:

Shape: Cylindrical batteries have a standard cylindrical shape with positive and negative terminals at the top and bottom, respectively.

Electrolyte: They typically use a liquid electrolyte.

Picures:

Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh

Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh

Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh

Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh

Cylindrical Lipo Battery Cells 523450 603450 3.7V 7.4v 1000mAh
