Specifications
Brand Name :
Handpack
Model Number :
HPK-12-24
Certification :
CE/RoHS/MSDS/
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
15,000pcs per week
Delivery Time :
5-7 working days for sample order,7-25 working days for bulk order
Packaging Details :
Box/carton(standard package)
Product name :
7.5Ah 12Ah 24Ah 100Ah Lithium Lead Acid Battery Pack Phosphate Iron Batteries For UPS Backup
Model number :
HPK-12-24
Nominal Voltage :
12V
Nominal Capacity :
24AH
Application :
Electric transportation,medical equipment,solar power system, electric power tools,etc
Type :
LiFePO4
Cycly Life :
>2000 cycles @1C 80% DOD
SInner resistance :
≦50mΩ
Warranty :
2 year
Description

7.5Ah 12Ah 24Ah 100Ah Lithium Lead Acid Battery Pack Phosphate Iron Batteries For UPS Backup​


Specifications

Items Standard Remark
Nominal voltage 12.8V
Typical capacity 24Ah At 0.2C discharge rate
Max continuous discharge current 50A
Over protection current 450±8A 30ms
Discharge cut-off voltage 10V
Charge voltage 14.4±0.1V CC-CV
Charge current 5A
Inner resistance ≤60mΩ
Operation temperature range Charge 0℃~+45℃
Discharge -20℃~+60℃
Storage temperature range 0℃~40℃ Capacity 80%
Humidity 5%≤RH≤85%
Shell material ABS
Weight About 3.4±0.5Kg
Size(L*W*H) (175±1)*(166±1)*(125±1)mm
Protection function Over charge protection,Over discharge protection,Over current protection,Balanced function,Temperature protection



























Battery Features

  • OEM/ODM order is welcomed
  • Low discharge rate, no memory effect
  • Short-circuit and overcharge protection
  • Low recurring operation cost
  • Eco-friendly
  • Minimal self-discharge, less than 8% monthly
  • Protection functions
    (overcharge/discharge/current protection, temperature protection, short current protection, balanced function)


Our Certificate
OEM 7.5Ah 12Ah 24Ah 100Ah Lithium Lead Acid Battery Pack Phosphate Iron Batteries For UPS Backup​

Company Information



FAQ

1. Are you factory?
A: Yes, we are factory at Shenzhen China. Welcome to visit our company at any time.

2. Do you have current sample in stock?
A: Usually we don't have, because different customers have different requests, even the voltage and capacity are the same, other parameters maybe different. But we could finish your sample quickly once order confirmed.

3. What's the delivery time for mass production?
A: Usually 15-25days, it depends on the quantity, material, battery cell model and so on, we suggest to check delivery time case by case.

4. OEM&ODM are available?
A: Sure, OEM&ODM are welcome and Logo can be customized too.

5. What is the normal lifetime about battery?
A: More than 800 times for lithium ion battery; more than 2,000 times for LiFePO4 lithium battery.

6. What is your MOQ?
A: 1PCS sample order can be acceptable for testing.

7. How to maintain the battery?
A: The battery should be stored in clean, dry, ventilated, dark environment
when not using,keep it after full charge, recharge it every 3 months or 6 months.

8. Why choose HANDPACK Battery?
A: 1) A professional sales team which provide consultant service and the most competitive battery solutions.
2) Wide-range battery products to satisfy different customer's requirement.
3) Quick response, every inquiry will be replied within 24 hours.
4) Good after-sale service, long product warranty and continual technique support.
5) With 15 years-experience for manufacturing lithium battery.
