Specifications
Brand Name :
Handpack
Model Number :
HPK-12-25
Certification :
CE/RoHS/MSDS/
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
15,000pcs per week
Delivery Time :
5-7 working days for sample order,7-25 working days for bulk order
Packaging Details :
Box/carton(standard package)
Model number :
HPK-12-25
Nominal Voltage :
12V
Nominal Capacity :
25AH
Type :
LiFePO4
Cycly Life :
>2000 Times at 100% DOD
Warranty :
2 year
OEM/ODM :
Acceptable
Certificate :
CE/UL/MSDS/ROHS/ISO9001/UN38.3
Inner resistance :
≤50mΩ
Description

12V25Ah Lithium Iron Phosphate Battery for Solar Energy Storage with Bluetooth

Quickly Details

  • Green product
  • Long standby time
  • One year warranty
  • Excellent safety performance
  • Excellent storage performance and low self-discharge rate
  • Short circuit testing passed
  • Overcharge testing passed
  • Over discharge testing passed
  • 150C thermal shock test passed
  • 1.2m drop testing passed


Battery Description

Items Standard Remark
Nominal voltage 12.8V
Typical capacity 25Ah At 0.2C discharge rate
Max continuous discharge current 25A
Over protection current 150±20A 35±10 ms
Charge voltage 14.6V CC-CV
Charge current ≤ 10A
Inner resistance ≤50mΩ
Operation temperature range Charge 0℃~+45℃
Discharge -20℃~+60℃
Storage temperature range 0℃~40℃ Capacity 80%
Humidity 5%≤RH≤85%
Shell material ABS




























Cautions
(1) Do not immerse the battery in water, and keep the battery in a cool dry surrounding if it stands by.
(2) Do not use or leave the battery at high temperature as fire or heater. Otherwise, it can overheat or fire or its performance will be degenerate and its service life will be decreased.
(3) Do not reverse the position and negative terminals.
(4) Do not connect the battery electrodes to an electrical outlet.
(5) Do not short circuit. Otherwise it will cause serious damage of the battery.
(6) Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
(7) Do not use the battery in a location where static electricity and magnetic field is great, otherwise, the safety devices may be damaged, causing hidden trouble of safety.
(8) Please use special lithium charger.
(9) It should be noted that the cell would be possible to be at a over-discharged state by its self-discharge characteristics in case the cell is not used for long time. In order to prevent over-discharging, the cell shall be charged periodically to maintain about 13.2V(Recommended 3 months one cycle).Over-discharging may causes loss of cell performance, characteristics, or battery functions.
(10) Do not disassemble battery.

Battery Pictures
12V25Ah Lithium Iron Phosphate Battery for Solar Energy Storage with Bluetooth
Standard Test Conditions
Battery test must within 1 month after production.
All test in this specification should be in standard atmospheric conditions:
Temperature:25± 5℃, relative humidity: 60±25%.

Electrical Performance

Test Items Test Methods Test Standards
Capacity retention rate After standard charge under 5.1 specified conditions, store the cells for 28 days, then discharge at 0.2C(A )to cut-off voltage. Capacity retention rate≥95%
Cycle Life Standard charge at 0.2C(A),rest 0.5~1 h,discharge at 0.2C to cut off voltage rest 0.5~1h, repeat the above steps until 2000 cycles. Capacity retention rate≥80%


FAQ
Q1: Are you trading company or manufacturer ?
A1: We are factory. Welcome to visit us.
Q2: How long is your delivery time?
A2: Generally it is 15-20 days, it is according to quantity.
Q3: Do you provide samples ?
A3: Yes, we could offer the sample.
Q4: What is your terms of payment ?
A4: For bulk order,30% T/T in advance ,balance 70% before shippment. For sample order,100% payment before production.

Q5: What kind of after sales service would you provide ?
A5: If you have any questions when using,just feel free to contact us,we have 24 hours service.
