12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
Specifications
Brand Name :
EA ENERGY
Model Number :
12.8V 7A
Certification :
CE MSDS UN38.3
Place of Origin :
CHINA
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability :
100000pcs Per Day
Delivery Time :
1-5 Work days
Packaging Details :
15*100*7cm 1pcs / carton GW:0.6kg
Model :
12.8V 7A 89.6Wh
Cell type :
Lithuim Polymer Battery
Diameter :
151mmL*94mmH*65mmW
Voltage :
12.8V
Capacity :
7A 89.6Wh
Impedance :
＜90mΩ
Standard charge current :
Constant Current 0.2C
Standard discharge current :
Constant Current 1C
Cycle life :
>2000 cycles
Certifications :
CE /UL/UN38.3/ MSDS
Description

12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control

Software BMS Control Energy Storage Battery 12.8V 7Ah 89.6Wh Deep Cycle LiFePO4 Battery

Quick details:

1. Diameter*Height: 151L*100mmH *65mmW

2. Nominal Voltage: 12.8V

3. Nominal Capacity: 7A 89.6Wh

4. Cycle life: 2000 cycles

5. Standard charging ways: CC / CV

6. Li-ion / Lithium Ion rechargeable LiFePO4 battery

7. CE , UL ,UN38.3 , MSDS compliant

Description:

Using the technology of lithium iron phosphate cell, superior safety,thousands of cycles, 100%DOD, under normal conditions.

Built-in automatic protection for over-charge, over discharge, overcurrent and over temperature.

Free of maintenance .

Internal cell balancing.

Lighter weight: About 40% ~50% of the weight of a comparablelead acid battery.

Can be charged using most standard lead-acid charges (set).

Wider temperature range:-20℃~60℃.

Support for Series application expansion (up to 51.2V) and two inparallel.

Specifications:

Electrical

Characteristics

 Nominal Voltage 12.8V
Nominal Capacity 7Ah@0.2C
Energy 89.6Wh
Internal Resistance 90≤mΩ
Cycle Life 2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
Self Discharge ≤3.5% per month at 25℃
Standard Charging Max.Charging Voltage 14.0~14.6V
Charging Mode At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, andthen,changed continuously with constant voltage of 14.6V until the current was notmore than 0.02C5A
Charging Current 1.4A
Max.Charging Current 3.5A
Standard Discharging Discharging Current 1.4A
Max. Continuous Current 7A
Max.Pulse Current 20A(<3S)
Discharging Cut-off Voltage 10.0V
Operating Condition Charge Temperature 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance IP55
Structure Cell & Format IFR26650 N35,4S2P
Casing Plastic
Dimension(L*W*H*TH) 151*65*94*100mm
Weight Approx. 1.06Kg
Terminal F2

Products Details :

12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control

12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control

Applications:

UPS

Solar &Wind Power System

Golf Cart

Electric Vehicle ,E-bike, E-rickshaw etc.

Lighting

12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control

12.8V 7Ah 89.6Wh Deep Cycle Lithium Battery Software BMS Control
