Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS
Specifications
Brand Name :
EA ENERGY
Model Number :
12.8V 24Ah
Certification :
CE MSDS UN38.3
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability :
100000pcs Per Day
Delivery Time :
1-5 Work days
Packaging Details :
27*27*15cm 200pcs / carton GW:16kg
Model :
24Ah 12.8V 4S6P
Impedance :
＜200mΩ
Voltage :
12.8V
Diameter :
26±0.2mm*65.3±0.2mm
Cycle life :
>25000 cycles
Standard discharge current :
Constant Current 3C
Cell type :
LiFePO4 Battery Packs
Capacity :
24Ah 300Wh
Standard charge current :
Constant Current 0.2C
Certifications :
CE /UL/UN38.3/ MSDS
Description

Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS

4S6P Lithium Ion LiFePO4 Battery Pack 24Ah 12.8V 300Wh LFP Battery Pack With BMS For Golf Car

4S6P Battery Pack Quick details:

1. Diameter*Height: 128*170*80mm (Lithium Ion 26650 size 4S6P)

2. Nominal Voltage: 12.8V

3. Nominal Capacity: 24Ah 300Wh

4. Cycle life: 2500 cycles

5. Standard charging ways: CC / CV

6. Li-ion / Lithium Ion rechargeable LiFePO4 battery cell

7. CE , UL ,UN38.3 , MSDS compliant

12.8V Lithium Ion Battery Description:
Deep cycle batteries, unlike cranking batteries, are designed to release power slowly.

They can be drained and recharged multiple times over their lifespan. While both are important,

deep cycle batteries are the ones that you depend on for most of your navigation and power.

These batteries are responsible for the trolling motor and other battery powered appliances on your gold car like your audio system, fish finder, and GPS

Lithium batteries last so long that the price per use is a fraction of traditional batteries.

Up to 100% capacity for 2,000 recharge cycles (100%DOD), 80% capacity at ≥4,000 recharge cycles (80%DOD), 50% capacity at ≥6,000 (50%DOD - battery half life)

Specifications:

NO Items Specification Remarks
1 Nominal Capacity 24Ah 0.2C 1A Discharge
0.2C 1A Discharge
2 Nominal Voltage/shipping voltage 12.8V/12.85-14.4V Voltage
3 Discharge Cut-off Voltage 8.0V 0.2C 5A Discharge
0.2C 5A Discharge
4 Charge Limited Voltage 14.4±0.03V 0℃～45℃
5 Standard Charge Current 1.2A 0℃～45℃
6 Standard Discharge Current 3A -20℃~ +60℃
7 Rapid Charge Current 0.5C 5A 10℃～45℃
8 Rapid Discharge Current 0.5C 5A -20℃~ +60℃
9 Max. Charge Current 1C 5A
Max Pulse Current 3C
10 Internal Impedance ≤180mΩ AC 1kHz condition
At AC 1kHz
11 Weight About 2246g Weight 2246±20g
12 Storage Temperature Range ≤1 month -20~ 45℃ Factory Voltage 12.8~14.4V
≤3 months 0℃~ +30℃ Ex-factory Voltage12.8~14.4V
≤12 months 20±5℃ 　

Products Details :

Lithium Ion LiFePO4 4S6P Battery Pack 24Ah 12.8V 300Wh With BMS

Applications:

The 12.8V 20Ah battery is built with BIKE Lithium's legendary LiFePO4 cells. 2,000+ recharge cycles (roughly 5 year lifespan at daily use) vs. 500 for other lithium batteries or lead acid. Plus twice the power of lead-acid batteries at half the weight.It is a great substitute for lead-acid batteries.
