1. Battery Characteristic

• High Voltage

We offer the rated voltage of 3.6V, the working voltage varies with the load, generally between 3.3V ~ 3.6V

• High Energy Density

We offer the specific energy density of 450Wh/kg

• Wide Operating Temperature Range

We provide a wide operating temperature range, from -55℃ to +85℃

• Stable Operating Voltage

Stable operating voltage, more than 90% of the capacity could be output with a fixed voltage

• Long Shelf Life

Under the condition of normal temperature, the battery self -discharge rate of no more than 2% per year

Battery sealing using the fully sealed structure to reduce the leakage of the battery, make the battery can be stored at room temperature for more than 10 years

2. Main Applications

• Security & alarms

Smoke detectors, security alarms, seismometers, locking system, monitoring system, etc.

• Marine & signaling

Life jacket, signal light, buoy, etc.

• Medical devices

Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.

3. Manufacturing Advantages

• There is advanced automatic technology in HCB;
• The passivation is well controlled during the production;
• Varity of solutions including high power, high capacity (hermetic & semi sealing), low temperature etc;
• The multiple cascade and parallel connecting ways and combining suggestions can be provided with you;
• Multiple safety design.
• It is over 20 years for HCB to produce the Li-SOCl2 batteries.

4. Company Advantages

• HCB quality management meets the standard GB/T19001-2008/ISO9001:2008;
• GB/T24001-2004/ISO14001:2004 is HCB Environment Management System standard;
• The drop test is workable of HCB battery;
• HCB can provide the report for safe transport of goods to the customers;
• The CE certificate can be given to you if required;
• The Rosh certificate can be given to you if required;
• HCB Battery has passed the UL standard;

5. FAQS of General Safety Instructions

• How about the storage environment of the battery?

The battery should be kept as dryly as possible when they are in storage.

• Is it ok to continue to use the battery when the abnormal heat release or leakage occurs?

When the abnormal heat release or leakage occurs, the battery is not able to be continued to use.

• If you have children at home, what should you pay attention when we use our battery?

You need to keep battery out of the children. Please call to a physician immediately if it is swallowed by children.

• Why should you keep the batteries away from the fire?

They will be hot very fast and can lead the gas and other toxic materials leakage if they are closed to fire.

• What can't you do to the batteries?

The batteries are able to be deformed or drilled into or damaged because the toxic materials or gas leakage may lead a big rupture.

• When the batteries are changed, what should you pay attention to?

The batteries of different electrochemical system, grades, or brands can’t be mixed because it would lead toxic material or gas leakage and/or a big rupture.

• What will happen if the batteries are thrown into the water?

The batteries are not able to put or thrown into the water because it would cause explosion.
