1. Battery Characteristic

• High Voltage

The nominal voltage of single cell up to 3.6V, the operating voltage varies with the load, normally between 3.3V and 3.6V

• High Energy Density

The specific energy density of each battery is 399Wh/kg

• Wide Operating Temperature Range

The battery with a strong adaptability to temperature can be in work between -55℃ ~ +85℃

• Stable Operating Voltage

Stable operating voltage, more than 90% of the capacity could be output with a fixed voltage

• Long Shelf Life

The battery self-discharge less than 2% per year at room temperature

Battery sealing using the fully sealed structure to reduce the leakage of the battery, make the battery can be stored at room temperature for more than 10 years

2. Main Applications

• Electrical equipment

Wireless electric power tools, computer RAM & COMS, UPS, CNC machine tools, (TPMS), camera, video camera, timer, calculator, electric toys, lighting equipment, etc.

• Security & alarms

Smoke detectors, security alarms, seismometers, locking system, monitoring system, etc.

• Tracking

RFID products, road toll transponder, IC cards, etc.

3. Manufacturing Advantages

• The technology in HCB is advanced and automatic;
• We can control the passivation of the battery very well;
• There are variety of solutions such as high power, high capacity or low temperature etc;
• We can provide multiple cascade and parallel connection ways and combining suggestions with our customers if they need;
• The safety designs are multiple.
• We have more than 20 years experience in the industrial technology of Li-SOCl2 batteries.

4. Company Advantages

• HCB quality management meets the standard GB/T19001-2008/ISO9001:2008;
• Environment Management System of HCB is conformity with GB/T24001-2004/ISO14001:2004;
• We have much experience in drop test package;
• The package of HCB battery is very safe and we can show you the report for safe transport of the goods to you;
• The CE certificate can be given to you if required;
• The Rosh certificate can be given to you if required;
• UL test is available for HCB Battery;

5. FAQS of General Safety Instructions

• In order to keep the battery safely, what should we do?

In order to store the battery, the environment should be dry enough.

• When the abnormal heat release or leakage occurs, what should we do?

The battery should be stopped to using when the abnormal heat release or leakage occurs.

• What is the first step when you would like to use our battery?

The manual should be read before the battery is used.

• What are you careful with if there are children beside when you use the battery?

Keep battery out of the children. If swallowed, please contact a physician at once.

• What is the effect of the signs + and - on the battery?

You need to follow the signs + and - on the batteries and make sure not to reverse. If batteries are wrongly used, they will be hot very fast and can lead the gas and other toxic materials leakage.

• Can the batteries be mixed to use on different electrochemical system, grades or brands?

When changing batteries be aware that batteries of different electrochemical system, grades, or brands should be not mixed. If different batteries are used or in case of using old and new batteries together this can discharge batteries due to different voltage or capacity. This can cause toxic material or gas leakage and/or violent rupture.

• Is it ok to put the batteries into the water?

The water explosion will be caused if you throw the batteries into the water.
