1. Battery Characteristic

• High Voltage
  Nominal voltage up to 3.0 V
• High Energy Density
  Specific energy density up to 260 Wh/kg
• Wide Operating Temperature Range
  -40°C to +85°C
• Long Shelf Life
  Self discharge rate is less than 2% per year at room temperature
  High capacity, stable performance, no passivation effect
  Glass-to-metal seal
  Bobbin and spiral structure is available for different applications

2. Main Applications

• Monitoring
  Animal health monitoring system,forest fire alert, smart irrigation system, etc.

• Security
  Smoke detectors, security alarms, seismometers, digital door lock system, etc.

3. Manufacturing Advantages

• Advanced automatic technology is used in HCB;
• Our manufacturing process of cathode is unique and advanced;
• The main solutions are high power, high capacity(hermetic & semi sealing). Low temperature etc;
• Providing multiple cascade and parallel connecting ways and combining suggestions;
• The reliability of the products can be proved by the long time storage date which is over 10 years.

4.Characteristics

• Lithium is the lightest of metals and it floats on water. It also has the greatest electrochemical

potential which makes it one of the most reactive of metals. These properties give Lithium the

potential to achieve very high energy and power densities permitting batteries with very long useful

life and small cell packages.

• Because Lithium reacts violently with water, as well as nitrogen in air, this requires sealed cells.
• High-rate Llithium cells build up temperature and pressure if they are short circuited or abused. Thus,the cell design needs to include safety vents, which release the pressure or rupture to prevent uncontrolled explosion.

5.Warining

Do not charge. When this battery is charged, gas is generated inside and raises internal pressure,

resulting in fire, heat generation, leakage or bursting.

Do not dispose of in fire, disassemble or heat in any way. It will damage the insulation materials

and the safety vent resulting in fire, heat generation, leakage or bursting.

Insert batteries properly. Keep polarities in the correct position aligning + and - correctly for

ALL batteries to avoid leakage or bursting.

Do not short-circuit. If the + and - come into contact with metal objects, short circuiting occurs

resulting in heat generation or bursting. When carrying or storing batteries, avoid direct contact with

metal objects such as bracelets or key chains by putting them in a separate bag.
