Meters Sensor Primary Li-SOCl2 Cylindrical Battery ER14250 Lithium Thionyl Chloride Cell 432Wh/Kg 1200mAh
Meters Sensor Primary Li-SOCl2 Cylindrical Battery ER14250 Lithium Thionyl Chloride Cell 432Wh/Kg 1200mAh
Meters Sensor Primary Li-SOCl2 Cylindrical Battery ER14250 Lithium Thionyl Chloride Cell 432Wh/Kg 1200mAh
Meters Sensor Primary Li-SOCl2 Cylindrical Battery ER14250 Lithium Thionyl Chloride Cell 432Wh/Kg 1200mAh
Specifications
Brand Name :
HCB
Model Number :
ER14250
Certification :
RoHS/UN/CE/UL
Place of Origin :
China
MOQ :
1K pcs
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/P, D/A
Supply Ability :
Two millions units per month
Delivery Time :
5 working days
Packaging Details :
Special design for Air/Sea/Courier transportation
Classification :
Bobbin
Storage Temperature :
≤30℃
Max Size(mm) :
Φ14.5×25.0
Weight(g) :
10
Energy Density :
432Wh/Kg
Maximum Continuous Current :
40mA
Maximum Pulse Discharge Current :
80mA
Description

Primary Li-SOCl2 Cylindrical Battery ER14250 Lithium Thionyl Chloride Cell 432Wh/Kg 1200mAh

Nominal Capacity 800mAh
Battery discharged at continuous current 0.65mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃
Nominal Voltage 3.6 V
Maximum Continuous Current 40mA
Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃
Maximum Pulse Discharge Current 80mA
Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃
Storage Condition

Temperature ≤ 30℃

Humidity ≤ 75%RH
Operating Temperature -55℃ to +85℃
Battery Dimension See drawing on pag
Max Weight 10.0g
Self-discharge Rate 2%
Max self-discharged rate at ambient temperature 23±2℃
Shelf Life 10 years
Ambient temperature 23±2℃

1. Battery Characteristic

  • High Voltage

The rated voltage of the single battery is 3.6V, the operating voltage varies with the load, normally between 3.3V and 3.6V

  • High Energy Density

We offer the specific energy density of 432Wh/kg

  • Wide Operating Temperature Range

The battery can be in work between -55℃ ~ +85℃

  • Stable Operating Voltage

Stable operating voltage, more than 90% of the capacity could be output with a fixed voltage

2. Main Applications

  • Oil & Gas
    Well pressure meters, float meters, logging while drilling(LWD), measure while drilling(MWD), etc.

  • Military & Defence
    Portable radio communications, night vision equipment & thermal images, torches & lamps, etc.

3. Bobbin Benefits
Excellent safety record, high capacity
Typical Applications
Low power consumption & long shelf life equipment,
like calculator, industrial PC CMOS, memory support power, etc.

Spiral Benefits
High discharging current, high load voltage
Typical Applications
High power consumption equipment, like water meter,indicating lights, etc.
