1. Battery Characteristic

• High Voltage

The rated voltage of the single battery is 3.6V, the operating voltage varies with the load, normally between 3.3V and 3.6V

• High Energy Density

Energy density up to 590 Wh/kg

• Wide Operating Temperature Range

The battery can be in work between -55℃ ~ +85℃

• Stable Operating Voltage

Stable operating voltage, more than 90% of the capacity could be output with a fixed voltage

• Long Shelf Life

Self discharge rate is less than 2% per year at room temperature
Glass-to-metal seal
Bobbin and spiral structure is available for different applications

2. Bobbin Benefits

• Excellent safety record, high capacity
• Typical Applications
• Low power consumption & long shelf life equipment,
• like calculator, industrial PC CMOS, memory support power, etc.

3. ER+UPC
The battery is designed specifically for applications requiring low backgroundcurrents combined with high current pulses. The battery combinesthe inherent benefits of bobbin type Lithium Thionyl Chloride cell with a novel hermetically sealed Ultra Pluse Capacitor.Which enhances the performance of the Lithium Thionyl Chloride cell to meet large pulse current requirements, thus providing greater performance and safety in comparison to jellyroll construction(spirally wound) type batteries.

4. Company Advantages

• Quality management system of HCB is conformity with GB/T19001-2008/ISO9001:2008 standard;
• HCB Environment Management System meets the standard GB/T24001-2004/ISO14001:2004;
• The battery can pass drop test if you need;
• Report for safe transport of goods can be provided with you if needed;
• We can provide you with the CE certificate if you need;
• Rosh Standard is workable for HCB Battery;
• UL Standard is workable for HCB Battery.

5. General Safety Instructions

• Do not reverse battery, follow strictly the signs + and – shown on batteries and appliances. If batteries are put in the wrong way they are bound to become hot very quickly. This can lead to gas or toxic material leakage and/or to a violent rupture.
• Do not incinerate of mutilate, may burst or release toxic material.
• Do not deform batteries. Batteries are not to be crushed, drilled into or damaged in any other way. This can lead to toxic material or gas leakage and/or violent rupture.
• Do not throw the battery into water. This can cause explosion.
• Do not charge primary batteries. This can cause gas leakage and will lead to violent rupture and/or fire.
• Battery compartment should provide sufficient space for battery to expand in case of abuse.

6. Use Warning

• Do not charge. When this battery is charged, gas is generated inside and raises internal pressure, resulting in fire, heat generation, leakage or bursting.
• Do not dispose of in fire, disassemble or heat in any way. It will damage the insulation materials and the safety vent resulting in fire, heat generation, leakage or bursting.Insert batteries properly. Keep polarities in the correct position aligning + and - correctly for ALL batteries to avoid leakage or bursting.
