CP603146 Li-MnO2 Primary Cell Battery For NB-IoT Smart Alarm
CP603146 Li-MnO2 Primary Cell Battery For NB-IoT Smart Alarm
CP603146 Li-MnO2 Primary Cell Battery For NB-IoT Smart Alarm
CP603146 Li-MnO2 Primary Cell Battery For NB-IoT Smart Alarm
Specifications
Brand Name :
HCB
Model Number :
CP603146/1950mAh
Certification :
UL/RoHS/UN/CE
Place of Origin :
China
MOQ :
1K pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
Two millions units per month
Delivery Time :
35 work days
Packaging Details :
Special design for Air/Sea/Courier transportation
Operating Temperature :
-40℃~+70℃
Self-Discharge :
≤2%
Peak pulsing current :
1000mA
Nominal Voltage :
3.0V
Nominal Capacity :
1950mAh
Maximum Continuous Current :
800mA
Description

Customizable CP603146 Li - MnO2 Soft Battery For NB-IoT Smart Alarm

Nominal Capacity

1950mAh
Nominal Voltage 3.0 V
Maximum Continuous Current 800mA
At +25°C, 2.0V cut-off, battery discharged for minimum 50% of rated capacity with max pulse for 3 seconds after 27 seconds break.
Maximum Pulse Discharge Current 1000mA
The discharged capacity may vary according to the pulse . characteristics, the temperature, and the cell’s previous history. Fitting the cell with a capacitor may be recommended in severe
conditions. Consult HCB.
Storage Condition (recommended)

Temperature ≤ 30℃

Humidity ≤ 75%RH
Operating Temperature -40℃ to +70℃
Battery Dimension (Thickness*Width*Height ) 6.2mm*31mm*46mm
Max Weight 16g
Self-discharge Rate 2%
Low self-discharge rate (less than 2% per year of storage at +20°C)
Shelf Life 10 years
Ambient temperature 23±2℃

1. Battery Benefits

● High Voltage Response, Stable during most of
the Lifetime of the Application
● Energy Density up to 830Wh/L
● Wide Operating Temperature Range (-40℃~+70℃)
● Low Self-discharge Rate (less than 2% per year of storage at +20°C)

2. Main Applications

● Security System
● Smart Metering
● RFID and Tracking System
● Wireless Transmitting
● Smart Home Devices
● Military Devices

3. Key Features


● Optimized Battery Structure,Full Discharge Capacity
● Super Long Endurance
● No Passivation
● GB 8897.4-2008,IEC 60086.4:2014 and RoHS
● Easy to Recover

4. Warning

● Do not charge

● Do Not Short Circuit

● Do Not Recharge

● Do Not Puncture
● Do Not Crush
● Do Not Dismantle
● Do Not Incinerate
● Do Not Mix New and Used Batteries
● Do Not Heat Above 100°C

5. FAQ

  • Which environment is workable to store the battery?

In order to store the battery, the environment should be dry enough.

  • What kind of situation should we stop using the battery?

We need to stop using the battery when the abnormal heat release or leakage occurs.

  • Could you supply different sizes of batteries according to my product?

Yes, you can send your requirements about size or capacity to us.

CP603146 Li-MnO2 Primary Cell Battery For NB-IoT Smart Alarm
