Constant Paper Testing Instruments Friction Testing Machine ASTM D4918 / ASTM D1894

Quickly Detail:

Application:

Paper coefficient of friction testing equipment can measure the coefficient of static friction and dynamic

friction when materials are sliding. It is applicable for the packaging trade, film plants, testing institutions and so on.

Test Standard:
ASTM D4918 ; ASTM D1894 ; ISO8295

Specifications:

1. Sample thickness: ≤0.2mm
2. Sliding piece size: 63×63mm)
3. Sliding piece mass: 200×2g
4. Slider-speed:100 ± 10mm/min, 125 ± 10mm/min, 150 ± 10mm/min third gear for section
5. Working-table board size: 200×470mm)
6. Digital display: Display static friction and dynamic friction at the same time automatically.
7. Measuring precision: ±2%
8. Velocity of sliding-piece movement: 100×10mm/min
9. Force measurement range: 0-5N
10. Power supply: 200V, 50Hz
Note:The computer can be an optional part.

Characters:
1, paper coefficient of friction testing equipment adopts the advanced design technique labeled by piecewise linear with real-time display and real-time analysis.
2, paper coefficient of friction testing equipment Calibration methods: intelligent calibration, reducing the error
3, Display: LCD showing working status and test results
4, paper coefficient of friction testing equipment adopts one chip microcomputer system with high speed, high precision, and high integration to intelligently control each functional module.
5, The core parts and the components are provided with imported or homemade superior products to guarantee precise, stable and long-term use.
6, paper coefficient of friction testing equipment has the communication function of the RS232 computer, and supporting control software to account, analyze and deal with the test results.
7, The specialized appearance design can easily mix with the office and test environment.

Picture:
