Wired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code Scanner
Wired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code Scanner
Wired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code Scanner
Wired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code Scanner
Specifications
Brand Name :
Luckydoor
Model Number :
K-6250
Certification :
CE FCC Rohs
Place of Origin :
Made in China
MOQ :
1pc
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
50K-60Kpcs / month
Delivery Time :
1-3 working days
Packaging Details :
Single standard packing box and carton
light source :
Visible LED
Scan type :
CMOS
Decoding :
QR,2D,1D
Resolution :
4mil
CO :
China
Interface :
USB,RS-232
Warranty :
1 year
Input :
DC5V
Description

Handheld 2D Barcode Scanner ,QR PDF417 DM 1D Bar Code Scanner Wired Barcode Reader with USB Cable

Product Description:

This 2D imaging barcode scanner is our newly developed and hot selling product ,it is aim to point of sales system, which can read merchandise barcodes like EAN13 fast and accurate.the USB interface allow end users integrate to their POS system quickly and easily , no need install driver or other special software,it is simple for new users to operate.

Product Features:

• Robust design, Plug-and-Play

• Buzzer & LED Indicator

• Read Poor Quality Bar Codes

• Excellent Bar Code Reading Performance From Paper and Screen

• Compatible with windows ,android,Linux OS

Product Specification:

Performance Parameters
Light Sources 617nm LED Aimer, White LED
Supported Symbologies

1D: Codabar, Code 11, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Code 128,

Interleave 2 of 5, Matrix 2 of 5, MSI Code, Industrial 2 of 5, GS1-DataBar.

2D: QR Code, Data Matrix, PDF417.
Scan Type Image CMOS
Scan Method Manual/Continuous/Automatic scanning
Scan angle Yaw 65°, Rotation 30°, Pitch 60°
Precision ≥5mil
Depth of scan field 60-250MM
Error Rate Less than 1/5million
Interface USB-HID, RS232
Physical Parameters
Dimensions 79.7mm*69mm*155mm
Weight 113.4g
Material ABS+PC
Cable Length 2m
Environmental Parameters
Operating Temperature -20℃~+60℃
Storage Temperature -40℃~+70℃
Relative Humidity 5%~95% RH(Non-condensing)
Drop/Shock Resistance Withstands multiple times 1.5 meters drops to concrete
Electrical Parameters
Voltage DC5V±5%
Operating Current 135mA

Product Pictures:

Wired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code ScannerWired 5mil Handheld 2D Barcode Scanner QR PDF417 DM 1D Bar Code Scanner

Product Application:

Warehouse and inventory management

Logistics and transportation

Postal and billing

Ticketing

Point of Sales system

Retail stores

Shopping mall and center

FAQ:

1, What is a 2D barcode scanner?

Those barcode scanners can decode 1d like EAN,UPC,Code 128 etc and 2d barcodes like QR,DM,PDF417 etc called 2D barcode scanner

2, What type communication this 2D handheld barcode scanner support ?

It is support USB-HID,USB-COM and RS-232 communication

3, Where can I get one unit to test the quality of this 2D barcode reader ?

You can buy from us directly ,we accept TT,Paypal,Western union payments ,and delivery parcel in 1-3 working days after payment received
