Through The Wall Mode Card Dispenser Kiosk Cold - Roll Steel Sheet

Specifications

Brand Name :

LKS or customized

Model Number :

LKS8305B

Certification :

CE, FCC

Place of Origin :

China

MOQ :

10 units

Price :

USD 800-20000 /Units

Payment Terms :

T/T in Advance

Supply Ability :

1000-2000 units per month

Delivery Time :

4-6weeks upon payment

Packaging Details :

Film Wrap,Foam and Wooden Box

Kiosk Type: :

Kiosk Design Ideas

Application: :

Banking, Retail,Post, Transport, Library,

Material of Cabinet :

Cold-roll steel sheet or others

Brightness :

250 cd/㎡

Supported OS :

windows 7 or windows xp /2003 or Linux or Unix

Material Feature :

Anti-dust, Anti-vandal

Description

through-the-wall mode for wall mounted kiosk :

Main components :

Industrious PC
15 inch IR touch screen
Speaker
Free standing single screen cabinet
Wireless Module
Receipt Printer
Cash dispenser
cash acceptor
Barcode scanner
Webcamera
Bankcard reader
Encrypted Pin Pad

Standard hardware components List is as following:

Main Components	Main specifications
PC system	Industrial Board	Seavo/ Gigabyte/Advantech AIMB 562
	CPU	Dual core E5700/G2030, 3.0GHZ; Intel Dual Core I3/I5/I7
	RAM	2GB /4 GB / 8GB
	HDD	500G
	Interface	6* RS-232 Ports;1* LTP;6 * USB Ports,8GPIO;1PCI
	PC Power Supply	HUNTKEY/Great Wall
LCD monitor	Screen Size	17/19 inch Diagonal ( optional from 8inch to 65inch)
	Brightness	250cd/m2
	Angle	horizontal 100°above;Vertical 80°above
	Contrast	1000:1
	Backlight Tube Life	more than 40,000hours
	Response Time	<5ms
	Max. Resolution	1280×1024
Touch screen	Screen Size	17/19 inch Diagonal ( optional from 8inch to 65inch)
	Touch Accuracy	center: <1.5mm
	Touch Accuracy	edge: <3.2mm
	Response Time	<16ms
	Voltage	DC5V+/-5%
	Interface	RS232,USB
	Glass Thickness	3mm
	Resolution	4096x4096
Card Reader	Reading Distance	>4cm
	Operating System	windows98,Me ,XP,2003 ,Unix and Linux
	Card Contact Number	200000 Secondary
	Operating Temperature	-20℃ to 60℃
	Whether Contact	Non-contact
	Interface	Serial ports,USB
Encrypted Pinpad	Key Lifespan	>2,000,000 times
	Key Activation Force	2~3N
	Key Trip	>=0.45mm
	Pin Input	10 numerical keys and 6 function keys
	Power Voltage	DC5V+/-10%,Max 200mA
	Protection Level	Ip65 static and ip54 dynamic
Cash dispenser	Denomination	2 denomination
	Cassette Capacity	214mm
	Dispensing Speed	4 note/sec
	Reject Capacity	about 50 notes
	Usable Note Size	width:100~162mm
	Usable Note Size	height:62~78mm
Cash acceptor	Validation Rate	96% or higher on first insertion
	Bill Path Width	62-77mm
	Bill Path Length	120-160mm
	Barcoded Coupons	lengthwise two-way
	Banknote Insertion	lengthwise Four-way
	Escrow	One bill
	Capacity	1000 notes Max
Coin Acceptor	Coin Acceptance	Max 32 coin types, in 216 or 132 channels
	Coin Accepted Size	Coin diameter: 15-31.5mm ( optionally up to 32.5mm)
	Coin Accepted Size	Coin thickness: 1.5-2.5mm ( optionally bis 3.3mm)
	Receiving Rate	>99.6%
	Accepting Speed	2 Coins /Sec
	Supply Voltage	12V-24V DC
Coin Dispenser	Dispensing Speed	12 note/sec
	Storage Capacity	1500 coin
	Coin Diameter	18~28.5mm
	Coin Thickness	1.65~3.2mm
	Power Voltage	DC24V
Receipt printer	Autocutter	included
	Technology	Thermal printing
	Paper Width	80mm
	Printing Speed	150mm/s
	Paper Thickness	0.06-0.15mm
	Supply Voltage	DC24V
UPS	Input Voltage	145-290va
	Output Voltage	200-255va
	Transient Time	≦10ms
	Max Time For Supplying a Single PC	3~20minutes (for single PC)
Digital Power Supply	AC Input Voltage Range	100‐240VAC
	Frequency	50Hz to 60Hz
	Output Over Current Protection	110~130%
	Frequency	50Hz to 60Hz
Accessories	Wire-Lan Port, USB Ports, Speakers, Fans, Cables, Screws, Etc.
Operation System	Windows 7 or Windows XP Operation System For Test
KIOSK Cabinet	Durable Steel Frame, Slim And Smart Design; Easy to Install And Operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free, Have Color And LOGO Upon Request.
Packing	Security Packing Method With Bubble Foam+Wooden Case

Other Optional hardware components List of popular shopping mall kiosk with advertising screen is as following:

1. A4 laser printer

2. Card dispenser

3. Metal keyboard with trackball

4. Fingerprint reader

Main picture of the wall mounted kiosk:

Process of followsheet of LKS Wall Mounted Kiosk :
