PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
Specifications
Brand Name :
Lohua
Model Number :
LHM-2B7CD040-00740AA
Place of Origin :
China
MOQ :
1,000pcs
Price :
$5-$10/pc
Payment Terms :
T/T
Supply Ability :
200,000 pcs/month
Delivery Time :
5 - 8 work days
Packaging Details :
normal packaging
Lamp Luminous Flux(lm) :
530lm
Color Temperature(CCT) :
4000K
CRI（Ra） :
97
Power :
6W
Series Parallel Relation :
2 parallel 7 Series
Electric Current :
0.3A
Input Voltage(V) :
18~24V
Material :
A1 panel
Description

Led Strip Module Bulb Light 6W Color Temperature(CCT) 4000K RA: 97

Product Features:

1. The CSP lamp beads can be customized, application extensive.

2. The RA is 97, which is very close to sunshine.

3. Low thermal resistance, Long lifespan, small size, high optical density.

4. Six core functions: high light efficiency, long lifespan, low energy consumption, high quality, no stroboflash, fast heat dissipation.

Product Parameter:

Optical Parameter Value Panel Parameter Value
Lamp Luminous Flux(lm): 530lm Series Parallel Relation: 2 parallel 7 Series
Color Temperature(CCT): 4000K Electric Current: 0.3A
CRI(Ra>): 97 Input Voltage(V): 18~24V
Power: 6W Thermal Conductivity: >2.0W/M.K
Lamp Luminous Efficiency(lm/w): 901Lm/W Material: A1 panel
Model Number: LHM-2B7CD040-00740A Brand Name: Lohua Light Source
Lamp bead model: 0909030-2828-5X-40AA Application: Various lighting places
Warranty(Years): 2 years Place of Origin: Shenzhen, Guangdong, China
CSP size(mm): 28*28 Name: 7W bulb light csp module
viewing angel(°): 150° LED Light Source: csp lamp bead
Luminous intensity: 530lm QTY of LED: 14pcs
LED Type: 2828 PCB Thickness: 1.0mm
Power Factor: >0.95 IP Rating: 66

Our Service:

1. Our own factory, with a overall quality control system.

2. We have patents in CSP, the quality is convinced.

3. With experienced experts, sales team and after-service team.

4. Various csp lamp bead, include dividual csp, easy to use.

Application Range:

It is widely applied in shopping malls, office buildings, hotels, exhibition halls, conference rooms, hospitals,windows, household etc.


Company Introduction:


Jiangsu Lohua New Material Co., LTD., founded in October 2013, located in National High and New Technology Industrial Development Zone of Nantong, is the first successful manufacturer of development and production of CSP products and fluorescent ceramic products in China. The company has always been based on the LED, a new generation of lighting and laser display technology, providing the overall solution of more high-quality light emitting materials and light source for the white light. It is a national high-tech enterprise of research, development, production, and sales of integration with sales team in Jiangsu, Guangdong, Sichuan Province and other places.

PCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp BeadsPCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp BeadsPCB 1.0mm SMD 2828 0.3A 6W 530lm 14pcs Led Lamp Beads
