PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
Specifications
Brand Name :
Lohua
Model Number :
LHM-2B7CD029-00740AA
Place of Origin :
China
MOQ :
1,000pcs
Price :
$5-$10/pc
Payment Terms :
T/T
Supply Ability :
200,000pcs
Delivery Time :
5 - 8 work days
Packaging Details :
normal packaging
Lamp Luminous Flux(lm) :
530lm
Color Temperature(CCT) :
97
Power :
6W
Lamp Luminous Efficiency(lm/w) :
901lm/W
Series Parallel Relation :
2 parallel 7 Series
Electric Current :
0.3A
Input Voltage(V) :
18~24V
Material :
A1 panel
Description

Led Bulb Module Downlight 7W RA: 97 Color Temperature(CCT)

Product Features:

1. Without gold in process, low malfunction rate.

3. The be customized, application is conveniently.

3. Large luminous Angle, perfect substitute for traditional incandescent lamp.

4. High effificiency, energy saving, long service life.

5. Green and environmentally friendly , healthy and eye protection.

Product Parameter:

Optical Parameter Value Panel Parameter Value
Lamp Luminous Flux(lm) 530lm Series Parallel Relation 2 parallel 7 Series
Color Temperature(CCT) 4000K Electric Current 0.3A
CRI(Ra>) 97 Input Voltage(V) 18~24V
Power 6W Thermal Conductivity >2.0W/M.K
Lamp Luminous Efficiency(lm/w) 901Lm/W Material A1 panel
Model Number: LHM-2B7CD029-00740AA Brand Name: Lohua Light Source
Lamp bead model: 1010030-3232-5X-40AA Application: Various lighting places
Warranty(Years): 2 years Place of Origin: Shenzhen, Guangdong, China
CSP size(mm): 32*32 Name: 7W downlight csp
viewing angel(°) 150° LED Light Source: csp lamp bead
Luminous intensity: 530lm QTY of LED: 14pcs
LED Type 3232 PCB Thickness 1.0mm

Our Service:

1. Will protect your sales area, ideas of design and all your private information.

2. We have strictly and high quality standard for the products' function, the appearance and performance.

3. We provide 2 years warranty for our consumer for our LED lighting products.

4. We have a factory with good adaptability can reach your requirements.

Application Range:

It is extensively applied in shopping malls, office buildings, hotels, exhibition halls, conference rooms, hospitals, windows, household etc.

Company Introduce:

Jiangsu Lohua New Materials Co., LTD., founded in October 2013, located in National High
and New Technology Industrial Development Zone of Nantong, is the first successful
manufacturer of development and production of CSP products and fluorescent ceramic
products in China. The company has always been based on the LED, a new generation of
lighting and laser display technology, providing the overall solution of more high-quality light
emitting materials and light source for the white light. It is a national high-tech enterprise of
research, development, production, and sales of integration with sales team in Jiangsu,
Guangdong, Sichuan Province and other places.

PCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED ModulePCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED ModulePCB 1.0mm 24V 0.3A 6W 530lm 3232 Round LED Module
