Waterproof 1500M Laser Range Finder Scope Distance Measuring Binoculars
Waterproof 1500M Laser Range Finder Scope Distance Measuring Binoculars
Specifications
Brand Name :
JSD
Model Number :
JSD-1230
Place of Origin :
ShenZhen
MOQ :
1pcs
Payment Terms :
T/T, T/T
Supply Ability :
30000pcs per month
Delivery Time :
7-10days
Measuring range :
3-1500m
Measurement accuracy :
±0.5m(<400m)
Measuring Range of speed :
18-300kM/h
Angle measurement error :
-20°to 20°
Field of view :
7.5degree
Magnification :
6X
Exit pupil diameter :
3.3MM
Laser type :
905nm(Class 1 Product)
Description

Waterproof 1500M Laser Range Finder Scope Distance Measuring Binoculars

Product Purposes and Key Features:

1. The product has 6X optical viewing system. It's easy for targeting, and it has four basic

functions of range, speed, angle, height measurement.

2. In addition, the product is with graceful appearance design which meets the design concept

of human engineering.

3. The product is designed to satisfied waterproof class of Ip5

4. The product comes with automatic shutdown function

Suitable for Measuring the Following Objects

The range of laser ranger finder is defined as the conditions below:

1. The reflectivity rate is moderate, such as building's wall.

2. The surface of reflector is vertical with the laser emission direction.

3. The day is sunny and measuring direction can't be face to the sunlight.

4. Tha area of refletor is no less than 2m*2m

Measurement Range 5-600m/1000m/1500m
Measurement Accuracy ± 1mm
Measurement Time 0.1- 0.3s
Operating Temperature Range -20°C ~ 50°C
Storage Temperature Range 0°C ~ 40°C
Unit Selection M/YD
Laser Light Type 905nm
Eye Relief 3.8mm
Objective Caliber 22mm
Eyepiece Caliber 16mm
Magnification 6X
Range of Anger Measurement <±90º
Display Mode LCD Screen
Field of View Angle 7º
Diopter Adjustable Range ±5º
Measuring Standard Switch √
Data clearing √
Battery indicator √
Signal strength indicator √
Continuous measurement( max/ min) √
Addition/ Subtraction √
Volume/ Area/ Pythagorean measurement √
Trapezoid Measurement √
Battery type CR2/3V*1
Size 115*77*45 mm
Weight 178 g

Funtion:

1. Distance measurement

2. Angle scan mode

3. Height measurement in scan scan mode

4. Golf mode

5. Vertical height measurement

6. Low battery indicator

7. Laser indicatior

8. Automatically shut off

9. Hoc tripod design

Features:

Humanized design

Rainproof structure

Supplement with angle meansurement

Professional and reliable measuring performance
