Border Surveillance Long Range Ptz IP laser Camera 1km Nir Night Vision
Border Surveillance Long Range Ptz IP laser Camera 1km Nir Night Vision
Border Surveillance Long Range Ptz IP laser Camera 1km Nir Night Vision
Border Surveillance Long Range Ptz IP laser Camera 1km Nir Night Vision
Specifications
Brand Name :
Hope-Wish
Model Number :
BRC1930
Certification :
CE,FCC
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Packaging Details :
wooden case
laser power :
10W
warranty :
one year
wave length :
808nm
Resolution :
1920*1080
Night Vision :
1 km
Application :
vehicle mounted
Description

1km NIR Night Vision Coastal & Border laser infrared Surveillance Camera

GRC20 series vehicle mounted optical system IR camera day/night laser camera. It consists of HD visible light cameras, laser illuminator, laser ranging, dynamic organization, precision gears, digital decoder, high-performance image processing unit and controller. All-reinforced structural design, super-strength stainless steel center bearing, multi-round reinforcement design, to ensure the equipment run properly under the condition of the vehicle bump.

Feature

  1. Consist of visible light camera, laser illuminator, laser ranging finder, anti-shock reinforcement pan tilt, accurate position.
  2. UFPA detector, detect 3km at night.
  3. 3km, 5km, 10km distance laser ranging finder, 3m range accuracy, accurate positioning.
  4. 30kg, 50kg anti-shock reinforcement heavy duty CNC pan tilt, 360 continuous rotation observation, no dead ends, smooth operation, image small dithering.
  5. Full-reinforced structural design, super-strength stainless steel center bearing, multi-round reinforcement designed to meet military vehicle environmental vibration, anti-shock requirements
  6. Housing using superior aluminum material, IP66 protection, anti-rain, anti-dust, can adapt to a variety of harsh environments.

Technical specification

Model GRC2132
Detection Day:2km;
　 Night:1km
Consumption 10W,808nm , NIR
Laser angle 1°～20°
Angle and distance matching DSS digital stepper illumination angle control, unique laser angle and distance matching technology, min 0.1°follow-up zooming
GHT-II super homogenizing HD illumination technology
0.01°SLM optical axis aiming and locking
Camera 1/2.8'' CMOS,star-class CMOS ,2 megapixel
　 Automatic ICR switch,H.264 video format
Lens 8-320mm HD lens , electrical zoom
Penetrate fog Optional, optical filtering and AFR electronic enhanced image processing technology, color penetrate fog

GPS

(optional)

 Positioning accuracy 10m
Time update cycle 1ms,100ms,200ms
Time Accuracy 0.001s
Baud rate 4800,9600,19200,38400,57600,115200
Sensitivity detect-148dBm,tracking-165dBm
PT and housing Housing Integrated multi-window, aluminum, with wiper, waterproof seal, IP66 protection class, dustproof and waterproof
Internal control circuit pan, tilt, rotate( PWM drive), the lens zoom, focus, camera DC12V power supply, laser ranging finder high and stable power supply DC24V ± 1V, color to W/B aux command, preset function, the thermostat function.
Load duty 30kg
Angle Pan 360 continuous, tilt + 45 ° ~ -45 °, PT azimuth display.
Speed Pan 0.01～15°/S; tilt 0.01～15°/S
Seismic reinforcement Super-strength stainless steel center bearings, with special damping base

LRF

(optional)

 Wave length 1.57um
Detection 50m—3km
(max 15000m)
Ranging Accuracy 3m
Repetition frequency 10 cycles / minute
Power supply DC24V
Interface RS422 full duplex
Others Interface 1*RJ45 network HD visible light video,
1* DC24V, 1*RS422
Ingress protection IP66
Operational temp. -35℃～+65℃
Weight 20kg—65kg(Based on specific configuration )
