ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm
Specifications
Brand Name :
LONGTENG
Model Number :
LT·ER80-G
Certification :
TUV CE, ABS, DB, ISO9001
Place of Origin :
CHINA
MOQ :
one pallet
Price :
USD 1
Supply Ability :
1,200,000 TON PER YEAR
Delivery Time :
15 WORKING DAYS
Packaging Details :
Neutral box/ LT color box/OEM brand box
Product name :
High Strength Steel Solid Welding Wire LT·ER80-G
Model :
LT·ER80-G (ER110S-G)
Brand :
LONGTENG
Diameter :
0.8/0.9/1.0/1.2/1.6mm
Weight :
1/5/15/20kg
Surface :
Cooper plating
Spool material :
Black plastic spool
Packing :
Color box
OEM :
Accept
Diameter of spool :
100/200/270/300mm
Description

LT·ER80-G 0.8/1.0/1.2/1.6mm High Strength Steel Solid Welding Wire

LT·ER80-G Conform to Standard :GB/T 8110 ER80-G

AWS ER110S-G

Features and Applications:
1. ER110S-G is low alloyed and high strength GMAW wire and GTAW rods
2. It is used for joining of the high strength low alloy steels and the fine grained constructional steels with minimum yield strength of 690 N/mm²,

3. especially Hardox and Weldox sheets
4. Boilers, pressure vessels, pipelines, structure steels are the other application areas
5. Weld metal has high impact and toughness at low temperatures
6. Pre-heat can be according to the base material
7. Shielding gases - MAG : (Ar+% 15-25 CO2) / TIG : (Ar)

Chemical Composition(%)

Chemical Composition C Mn Si S P Cr Ni Mo Cu
Guarantee Value ≤0.11 1.40~ 0.40~ ≤0.025 ≤0.025 0.25~ 1.20~ 0.20~ ≤0.50
1.85 1 0.6 2.4 0.6

Mechanical Properties of Deposited Metal(Ar+20%CO2)
Test Item Rm(MPa) ReL/Rp0.2(MPa) A(%) KV2(J)
-20℃
Guarantee Value ≥790 ≥690 ≥17 ≥27
General Result 840 730 24.5 85,93,75

Notes:

1. Shield gas: Must ensure not to operate with impurity shield Gas

2. Operation flow rate of shield gas: 20-25L/min.

3. Electrode extension: 15-25mm
