Specifications
Brand Name :
TimeWave
Model Number :
Type YW-TW
Certification :
ISO/IEC 20000-1,ISO/IEC 27001,ISO/IEC 9001
Place of Origin :
Hubei , China
MOQ :
Negotiable
Price :
EXW price US$ 80-550/ set
Payment Terms :
L/C, T/T
Supply Ability :
2000 sets per week
Delivery Time :
3-5 weeks after receive the payment
Packaging Details :
Customizable packaging
Name :
LoRaWAN Smart Gas Meter
Reading distance :
＞3000m
Display :
LCD screen
Shell :
Aluminum/steel shell
Description

Prepaid LoRaWAN Gas Meter Wireless IoT Remote Control LCD Aluminum Steel Shell Ultrasonic Gas Meter

  • Product Overview

​Intelligent gas meter is a new generation of centralized reading gas meter terminal. It is applicable to the flow measurement of natural gas, liquefied petroleum gas, artificial gas and other gases. It integrates gas meter metering, remote reading and monitoring. The meter has the characteristics of high reliability, high accuracy and low power consumption.

Type YW-TW intelligent gas meter based on the IoT adopts LoRaWAN/CAT.1 wireless transmission technology. Automatically upload gas consumption data to the application platform to realize remote monitoring of gas meter usage status. It solves the problems of the traditional gas meter, such as the difficulty of over-reading the meter at home, the difficulty of paying the fee,and the inaccuracy of the supply and marketing difference.Explosion-proof sign ExibIIBT3 Gb. It is applicable to Zone 1 and Zone 2, containing IIA-IIB and T1-T3 explosive gas mixture.
  • Functions and features

​1. Adopt LoRaWAN wireless technology. Effectively increase the anti-interference ability of the communication system and improve the accuracy of the received data.

2. The gas meter adopts the form of system prepayment. The valve switch of the gas meter is realized by the command from the system platform.
3. Timing (once a day)(settable) and key wake-up to transfer data to the platform. It improves the response speed of meter reading and reduces battery energy consumption.
4. When the voltage is low or abnormal,the LCD screen will automatically display the fault information, beep the alarm, and close the valve.
5. It has a built-in antenna.The transmission signal is stable and reliable.
6. The platform can remotely check the user's gas consumption,battery usage,and remotely control the valve switch of the gas meter.
7. It has the function of pulse signal open circuit self-inspection,which can effectively ensure the accuracy of gas meter measurement.
  • Display Description

​

  • Specifications & technical parameters
Specifications G(J)1.6 G(J)2.5 G(J)4
Nominal flow(m3 /h) 1.6 2.5 4
Maximum flow(m3 /h) 2.5 4.0 6.0
Minimum flow(m3 /h) 0.016 0.025 0.040

Working Pressures(kPa) ≤30
Total Pressure Loss(Pa) ≤250
Accuracy Level 1.5 Class
Basic Error Lines qmin≤q< qt ±3.0% qt≤q≤qmax ±1.5%
The tightness of the machine It can last for 3 minutes without leakage under 1.5 times of the maximum working pressure
Operating Ambient Temperature(℃) -25℃～ +40℃
Inlet and Outlet Connector Threads M30×2
Maximum Display Capacity of LCD(m3) 999999
Maximum reading of base meter(m3) 99999.999
Power supply mode Four AA Alkaline dry batteries(AA LR6 1.5V)
LoRaWAN frequency band (MHz)
CN470,RU864,IN865,EU868,US/AU915,KR920,AS923_1/2/3/4,
Custom Channels
Barrier-free meter reading distance >3000m
Compliant standards GB/T 6968-2019,GB/T 3836-2021
