Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
Specifications
Brand Name :
LP
Model Number :
LP-FH020
Certification :
ISO-9001：2000
Place of Origin :
China
MOQ :
1000pcs
Price :
0.0001
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
100000pcs
Delivery Time :
7~10 days
Packaging Details :
Tube / Polybag
Color :
Black
Description

Product Description
PCB connector component type: PCB mounting parent
Connector system: board to board
Type of connector: with hood
Connector and terminal end connection: printed circuit board
Number of loading locations: 10
The number of rows: 1
PCB mounting direction: vertical
Number of Positions: 10
Operating Voltage (VAC) : 125
Dielectric withstand voltage (maximum) (VAC): 650
Connector profile: Standard
Terminal base material: phosphor bronze
PCB terminal end area electroplating material: gold-plated
Electroplating material of terminal contact part: gold-plated
Terminal rated current (Max.) (A): 2
Shell color: black
Shell material: LCP (Liquid crystal polymer)
Operating temperature range (°C): -40 -- 125, -40 -- 125
Operating temperature range (°F): -40 -- 257, -40 -- 257
Shell temperature rating: High
UL flame retardant rating: UL 94V-0

Female header, PCB Mount Receptacle, Vertical, Board-to-Board, 10Pin, 1.0mm Pitch, single row, Gold Flash, DIP, 180°
