Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Specifications
Brand Name :
Star Trailer
Model Number :
SW-014
Certification :
ISO/CCC
Place of Origin :
Shandong China (Mainland)
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T
Supply Ability :
300 units per month
Delivery Time :
40 days after receiving your payment
Max Payload :
60T
Size :
12550mm*2590mm*2702
Material :
Steel
Brand name :
Star Trailer
Axle brand :
FUWA OR BPW
Description
Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport
Overview
Quick Details

Use:Truck Trailer Type:Semi-Trailer Material:Steel

Certification:CCC/ISO Size:12400*2500*3650 OEM No.:Optional

Max Payload:50T Brand Name:StarTrailer Model Number:Shuyue

xle:FUWA 13 tons Brake:Wabco Floor thickness:3mm
Supply Ability

Supply Ability: 300 Unit/Units per Month 2 or 3 units packaged together to reduce the shipment cost.

Packaging & Delivery

Packaging Details

Nude

Port: China Port

Lead Time : Around 40 days after payment

Type 3 Axles Van Semi Trailer
Dimension
Size 12500*2500*1550mm
Weight
Payload 30,000kg
Tare weight Approx. 1,100kg
G.V.W.R Approx. 41,000kg
Frame&Structure
Main beam Material Q345B,Fabricated”H”beam height 500mm,Top flange thickness 14mm,Middle web thickness 8mm,Bottom flange thickness 16mm
Side beam 16#channel steel
Platform 3mm thick chequer plate with supporting channel
Stand column Standard design with support to the frame body
Roof Steel ,water proof design
Cross beam 80*40mm square tube
Kingpin JOST 2"SAE kingpin,bolted in type
Welding standard All welding are to be done by qualified welder per applicable national standard
Painting Shot blast at standard SA2.5 prior to application of primer,polyurethane top coat. Total DFT not less than 100um
Running gear
Suspension echanical suspension,leaf spring 13mm×90mm,China
Axle FUWA150×150square beam axle,3pcs*13ton capacity,China
Brake system Duine pneumatic brake,SAE hose and connector
Brake chamber 4 units T30/30 spring brake chambers,2 units T30 brake chambers
Air tank 40L,2pcs,China
Emergency relay valve Shunanda relay valve
Tire Double coin brand,12R22.5.12pcs, China
Rim 9.0*22.5 steel disc wheel,10 holes ISO,12pcs,China
Landing gear Standard 28T two speed telescopic manual landing gear

Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport

Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport

Company Information

As a leading Chinese vehicle exporter, we have many years professional experience in this field.

Besides the high quality of our vehicles, our international sales team will also provide you excellent logistics service and after-sales service.

We will always do our best to solve all the problems and put our customer's interests in the first place.

Our workshop

Our factory has perfect inspection equipment and advanced inspection methods.owns inspection

line and physic&chemical analysis rooms of special vehicle. large modern factory building of 3000

square meters ,own advanced production line,painting line and technical equipment for special

vehicles,and has annual design production capacity of 20000 vehicles.

Box 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van TransportBox 3-4 Axles Flatbed Container Trailer 60-100Tons Dry Food Van Transport

Our Services

Pre-Sales Service

The company has perfect inspection equipment and advanced inspection methods,owns inspection

line and physic and chemicial analysis rooms of special vhicle,and makes over 200inspection items

such as rear lower part protection,side protection,ABS braking and anti-skid brake system strictly

according to national standards for special vehicles.

After-Sales Service

1).Training trailer operating and normal maintenance.

2).Regularly call back to know the vehicle's working status.

3).Supply the service of regular repair.

4).The overaseas engineers are always ready to deal with unexpected needs.

5).CKD and SKD are available.
