3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
Specifications
Brand Name :
Stsr trailer
Certification :
CCC ISO
Place of Origin :
Shandong China
MOQ :
1unit
Payment Terms :
L/C, T/T
Delivery Time :
40 days after down payment received
Packaging Details :
nude
Price :
Negotiable
Model Number :
SW-010
Description
3/4 Axles Drop Deck Semi Trailer , Heavy Duty Semi Trailers For Truck
Overview
Quick Details

Use:Truck Trailer Type:Semi-Trailer Material:Steel

Certification:ISO CCC Size:13000*2550*600 OEM No.:

Max Payload:40 Tons Place of Origin:Shandong, China (Mainland)

Brand Name:Star Trailer Product Name:Sidewall Open Semi Trailer

Axle:13 Ton Fuwa Brand Function:Cargo Transportation

Axle Number:3 Axle Loading Capacity:40 Tons

Color:Option Tire:Option

Suspension:Leaf Spring Suspension

Supply Ability

Supply Ability:3000 Unit/Units per Year

Packaging & Delivery

Packaging Details:Standard Package

Port:Any port in China

Lead Time :

Quantity(Units) 1 - 10 >10
Est. Time(day) 25 To be negotiated

Specification:

Contract No.:
Type: 12.55M 4 Axle Drop Side Trailer
Model: WL840
Dimension:
Overall Length: 12,550mm
Overall Width: 2,580mm
Overall Height: 2,950mm
Axle space: 6,515mm+1,310mm+1,310mm+1,310mm
Weight:
Payload: 80,000kg
Tare weight: Approx. 9,900kg
G.V.W.R.: Approx. 89,900kg
Frame & Structure:
Main beam: 500×140mm,Top flange 16mm,web 8mm,lower flange 20mm,Q345B.
Kingpin: 2” Kingpin, Welded in type
Twist lock: 12 sets twist locks
Drop side: 1000mm
Landing gear: Telescopic manual leg JOST E100
Painting: Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 120μm
Running gear:
Suspension: Leaf spring(8pcs)
Axle: BPW 13 ton capacity 4Pcs
Tire: 12.00R22.5 18 Pcs(2 pcs of spare tire)
Rim:

9.0×22.5 18Pcs(2 pcs of spare tire)
Brake System:
Brake control valve: Sealco Relay emergency valve
Coupler: Gladhand coupler
Brake chamber T30,(T30/30) spring brake chamber

Electrical System:
Voltage: 24 Volt
Receptacle: 7 way socket SAE standard
Front marker lamp: White
Side marker lamp: White & Red
Rear lamp: Red
Turn signal lamp: Amber

Accessories:
Mud guard: Steel mud guard
Spare wheel carriers: 1 pcs
Tool box: 1 pcs
Other items:
1
2
3
Note: All the details not mentioned above should comply with Chinese regulations. If any component or structure changed, the price shall be modified accordingly.
