Use:Truck Trailer Type:Semi-Trailer Material:Steel

Certification: ISO CCC Size:12500*2500*1550mm OEM No.:Star Trailer VEHICLE

Max Payload:80T Place of Origin:Shandong, China (Mainland)

Brand Name:StarTrailer Product name:60tons 40ft Flatbed Side Wall Semi-trailer

Function:Transport 20/40ft container and Heavy Duty Cargo

Axle:13T 14T 16T 18T BPW FUWA QUEST

Suspension:Mechanical Suspension/Air suspension

Landing Gear:JOST Tire:11.00r20 12r22.5 315 385

King pin:2"(50mm)or3.5"(90mm) JOST

Color:Customers Optional Production time:40 days after receive workdays

Packaging & Delivery

Selling Units:Single item

Single package size:1250X250X155 cm

Single gross weight:7000.0 kg

Package Type:In nude 2 units side wall semi trailer canbe packed into 1*40ft HQ container

Lead Time :

Quantity(Set)	1 - 10	>10
Est. Time(day)	40	To be negotiated

Priduction Parameters

Specification:
Contract No.:
Type : Drop side Semi-trailer

Dimension:
Overall Length: 12,550mm
Overall Width: 2,590mm
Overall Height: 2,702mm
Axle space: 7,115mm+1,310mm+1,310mm

Weight:
Payload: 60,000kg
Tare weight: Approx. 8,300kg
G.V.W.R.: Approx. 48,300kg

Frame & Structure:
Main beam: Top flange 14mm,web 8mm,lower flange 16mm,Q345.
Floor: 2400x1260mm,5mm chequered plate
Kingpin: 2” JOST Kingpin, welded in type 1200mm
Bulkhead height: 1200mm
Container locks: 12pcs
Drop side: 600mm
Painting: Shot blast to SA2.5Standard prior to application of primer, polyurethane
top coat. Total DFT not less than 100um

Running gear:
Suspension: Leaf spring, 8pcs
Axle: BPW 13 ton
Relay Emergency valve: Sealco
Coupler: Gladhand coupler
Brake chamber: T30(T30/30) spring brake chamber
Tire: 12R22.5, 14pcs (2 pcs of spare tire)
Landing gear: JOST A400

Electrical System:
Voltage: 24 Volt
Receptacle: 7 way socket SAE standard, Philips
Front marker lamp: White
Side marker lamp: Amber
Rear lamp: None
Turn signal lamp: Amber

Accessories:
Mud guard: Steel mud guard
Tool box: 1 pc
Spare wheel carriers: 2 pc

High Quality 60tons 40ft Flatbed 3 Axles Drop Side Wall Semi Trailer For Truck

Product Introduction:

Our StarTrailer VEHICLE provide the flat bed trailer can be used to transport containers ,bulk cargo and other goods , and we also can according to your requirements to make this trailer.StarTrailer production the flatbed trailer all configurations and accessories used domestic and aboard famous brand. Our main beam material use Q345B,it has high-strength and strong stiffness features.other type flatbed trailer , like extendable flatbed trailer , flatbed trailer for transporting logs , and flatbed trailer with side wall.

Other items:
1
2
3
Note: All the details not mentioned above should comply with Chinese regulations. If any
component or structure changed, the price shall be modified accordingly

Features:

1,Steel construction:All chassis adopts the high-tensile steel

2,Running system:Axles and suspensions system are complied with International Standards;

3,Brake system:Adopt the International brands;

4,Electric system:China famous brands;

5,Painting:zinc-rich primer and modified urethane topcoat as customers' choices

6,Harness: We adopt the rubber Wiring harness. Its advantages include waterproof, dustproof, anti-aging, safety more,etc.Specially there are some high intension clamps to fix the harness.

7,The side beam is high tensile steel which strengthen more the Cargo platform.

8,Double air chambers are adopted on all axles in order to brake the trailers safety and quickly.

9,Lights include the rubber grommets in order to decrease the shaking and extend its using period. Specifications:

OUR ADVANTAGES

Novel design: Drop side trailer of Shandong Shuyue Vehicle Co., Ltd. is a new light vehicle, Which makes several innovations on the basis of full data analysis on transportation environments in various places, by fererring to foreign and domestic advanced design concepts and by using FEA (finite element analysis)

High strength steel: Material of web plate and key position uses high strength low alloy steel with domestic advanced technical standard .

Strong loading capacity: By using high strength steel and structural innovation, it keeps same loading capacity while reducing while reducing tare weight. It is unique in reducing oil consumption and tire wearing aspects.
