3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
Specifications
Brand Name :
star trailer
MOQ :
1
Model Number :
FT2-003
Certification :
CCC/ISO
Place of Origin :
Shandong China (mainland)
Payment Terms :
L/C, T/T
Supply Ability :
300 units per month
Delivery Time :
25 days after payment
Price :
Negotiable
Size :
12000x2496x1650
Max payload :
40T
Material :
Steel
Type :
Semi trailer
Use :
Truck trailer
Description

3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm

Container flatbed semi -trailer laden parts of the container structure. Mainly used in ships, ports, route, highway, transit stations, bridges, tunnels, supporting intermodal logistics system. They are designed to transport a variety of containers. Long-term repeated use , has sufficient strength.

Overview
Quick Details

Use:Truck Trailer Type:Semi-Trailer

Material:Steel Certification:CCC

Size:12000x2496x1650 OEM No.:40T Container Truck Trailer

Max Payload:40T Place of Origin:Shandong, China (Mainland)

Brand Name:Star Trailer Model Number:Flatbed Trailer

Trailer Model:40T Container Truck Trailer Color:optional

Axle Number:3 Axle Brand:FUWA13TON

Landing Gear:JOST brand Tyre:12R22.5 Radial tyres

Wheelbase:6260+1310+1310

Supply Ability

Supply Ability:300 Set/Sets per Month

Packaging & Delivery

Packaging Details

polished with wax before shipping

Port

Any ports of China

Star Trailer 3 Axles Flatbed Semi Tralier/20ft 40ft Container Truck Trailer

Product Description

*40ft container flatbed carrier
*Durable semi trailer
*Better solutions
*Two units of trailer fit into one 40ft container

Name flatbed trailer with front board
Tires Specifications

Double coin brand, 825R20, 8 pcs. China
Rims

6.5-20 steel disc wheel, 10 holes ISO, 8 pcs. China
Axles

FUWA 150x150 square beam axle, 2pcs*13 ton capacity, China
King Pin 50#/90#

Landing gear:

JOST C200 two speed telescopic manual landing gea
Pieces of leaf-spring 10/10/10 thicken
Suspension

JMCG mechanical suspension, leaf spring 13mmx90mm, China
Material of the Main Beam

Q345B

Side beam

20# channel steel

Platform:

4mm thick chequer plate with supporting channel
Brake System

Dual line pneumatic brake, SAE hose and connector
Brake Air Chamber

4 units T30/30 spring brake chambers, 2 units T30 brake chambers
Electrical 24V 7 ways(7 wire harness) LED light
Color Any color will be available

Accessories

 One tooling box Steel mud guard
Painting

Sand blasting

One time Primer coating

Two times finish coating
Spare wheel carrier 2

Accessories:

3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm3 Axles Steel Flatbed Semi Trailer Mechanical Suspension Leaf Spring 13mmx90mm
