Specifications
Brand Name :
Startrailer
Model Number :
CM-004
Certification :
ISO、CCC
Place of Origin :
Shandong Province, China
MOQ :
1 unit
Price :
USD18000-USD9000
Payment Terms :
T/T
Supply Ability :
50 units per month
Delivery Time :
39 days after receive payments
Packaging Details :
One unit per package loaded on the Flat-rack transport by container vessel;
Tank material :
4mm thickness SM490A
Dished Ends :
5mm thickness SM490A
Discharging Hose Diameter :
4 inches
Discharging valve :
4” butterfly valve
Axle :
3T Axle FUWA/BPW Brand
Max Payload :
80T
Description

White Three Axles Carbon Steel Dry Bulk Truck Carriers Max Payload 80 Tons

Whatsapp: https://api.whatsapp.com/send?phone=8613864856071

YOUTUBE: https://www.youtube.com/user/BenjaminDuBin

Cement tanker refers to the special tank truck that transports bulk powder, such as cement, fly ash, stone powder, aluminium powder, etc. Among them, the bulk cement tank is the largest. The use of bulk transportation can improve transportation efficiency, save transportation costs, reduce environmental pollution during transportation and use, reduce production costs, and at the same time enable mechanization of loading, unloading and storage.

Overview
Quick Details

Purpose: Logistics between cities Type: Semi-Trailer

Material: Carbon Steel Certification: ISO CCC

Size: 12000*2500*3900mm Max Payload: 80T

Place of Origin: Shandong Province, China Brand: Startrailer

Utility hole cover:500mm, 1piece Axle:13T Axle FUWA/BPW Brand

Landing Gear: Standard 28 ton, JOST optional Tire:12R22.5 /11.00R20

Brake System: Dual line pneumatic service brake system.

Three-Axle Air Discharge Tanker For Carrying Dry Bulk Cement Tank Semi Trailer

White Three Axles Carbon Steel Dry Bulk Truck Carriers Max Payload 80 Tons

Specifications:

Type: Air Discharge Tanker For Carrying Cement

​DIMENSION:

Overall Length: 11,035mm

Overall Width: 2,500mm

Overall Height: 3,830mm

King Pin Setting: 1,515 mm

King Pin Plate Height: 1, 300 mm

King Pin to Landing gear: 2,550 mm

Wheel Span: 7,110 mm

Axle Spacing: 1,300 mm

TANK:

Tank Volume: 30,000L

Tank material: 4mm thickness SM490A

Dished Ends: 5mm thickness SM490A

Pipe material: Carbon steel

Discharging Hose Diameter: 4 inch

Discharging valve: 4” butterfly valve

Releasing Hose Length: 5,000mm

Hose quick coupling: 4” JG/T5021-93 (Chinese standard)

MAX. Horizontal Discharging Distance: 5,000mm

MAX. Vertical Discharging Distance: 15,000mm

Working pressure: 2 bar

Diesel engine: YANGZHOU 495GI

Air Compressor: WB-7/2

RUNNING GEAR:

Suspension: Undermount tandem suspension with equaliser,8-Leaf Spring.

Axle: Square axle, 13,000 kg capacity. (TSU13010)

Brake: Dual lines pneumatic brake system.

Parking Brake: Type 30/30 spring brake system on all axles.

Wheel: 10 holes steel Disc wheel.

Tire: 11.00x20 16 ply rating ,9 pcs (including one spare tire)

Kingpin: 2”.

LANDING LEG: (TSU CL25TA).

Two-speed manual operation type with the sandshoe.

ELECTRICAL:

Voltage: 24 Volt.

Receptacle: 7 way

Light: Front marker lamp: white

Side marker lamp: white and red

Rear lamp: red

Turn signal lamp: amber

STRUCTURAL WEIGHT RATING:

Tare Weight : 10,000kg

Payload : 23,300kg

G.V.W.R.: 33,300kg

King Pin Weight : 15,300kg

Axle Weight: 18,000kg

White Three Axles Carbon Steel Dry Bulk Truck Carriers Max Payload 80 TonsWhite Three Axles Carbon Steel Dry Bulk Truck Carriers Max Payload 80 Tons

Drawing

We have 20 years experience of engineering management in cement semi trailer operation, our engineer has designed and built trailers for container terminals in Rotterdam, Felixstowe, Russia, Egypt, Singapore, Indonesia, Pakistan, South Korea, ……. covering 23 countries and regions.
