Galvanized steel thermal solar water heater low pressure solar water heater
(1) Product Description

BABYSUN SOLAR has thousands of galvanized steel thermal solar water heater baths installed throughout Ancash, Puno, Juliaca, Arequipa, Lima, Cusco and other departments of Peru, the German technology with which they are made, allow us to offer 100% efficiency. It is important to emphasize that we have the European CE Certification. The key component of our galvanized steel thermal solar water heater are vacuum borosilicate tubes, which heat water up to 100 degrees Celsius. Unlike galvanized steel thermal solar water heater with solar panels, our thermal baths with vacuum tubes represent greater efficiency, since the tubes being round capture the solar rays in all their directions and angles, however, the plates only capture the perpendicular rays.

In addition, galvanized steel thermal solar water heater work in all types of weather (even cloudy) since they work with UV rays and not only with sunlight and heat. They are a high quality product, so we give you a 10 year warranty but they have a 20 year life. We have small galvanized steel thermal solar water heater for simple domestic use and on the other hand, hot springs with sophisticated facilities for industrial and / or business cases. 100 Lt. 150 Lt. 200 Lt. 250 Lt. 300 Lt. and of greater capacities.

(2) Technical Specification:
Solar Water Heater Inner Tank:
Food grade SUS 304 stainless steel/316 stainless steel, 0.4-0.6mm, diameter 360mm/380mm
Solar Water Heater Out Tank: Galvanized steel/201 stainless steel/304 stainless steel, 0.4mm, diameter 460mm/480mm
Insulation: 50mm high-density polyurethane foamed
Inlet&Outlet: 1/2” or 3/4”, stainless steel
Vacuum Tube: QB-AL-N/AL-47mm/58mm-1800mm
Water Tank Bracket: Galvanized steel sheet, 1.5mm/201 stainless steel, 1.2mm/aluminium alloy, stainless steel screws & nuts

(3) Optional Accessories and their Function:
Assistant tank: to add water automatically;
Electric heater: to heat water when rainy and cloudy days;
Magnesium anode: to soften water in hard water area;
TK-8A/TK-7/TK-5 digital controller: to read and control water temperature and water level

(4) Our Advantage:
1. Solar water heater with assistant tank modelnew design side assistant tank for hard water area;
2. Non-welding technology

(5) Application:
The main use is for family use, such as bathing, cloth washing and so on.
Solar water heater with assistant tank model is widely used in apartment, hotel and school.
Also it can be used for swimming pool, farm.

(6) FAQ
1- What is your Delivery Time?
LCL order/Sample order: within 7 days.
Full container order: 7-14days.
2- What is your Guarantee Time?
5 years.
Provide you with 1%-2% extra accessories and vacuum tubes, they are free for you.
3- Can you accept OEM ?
YES.
4- What is your Payment Term?
We accept T/T or L/C at sight, Western Union.
5- What is your MOQ?
1 set.
6- What is your Packing?
LCL order/Sample order in wood cartoon.
Full container order in high quality standard export carton.

7- What is your FOB Port?
We accept FOB Shanghai, Ningbo etc.
8- What is your Monthly Production Capacity?
10000 sets.
9- What is your Shipping Term?
By Sea/Air/Rail.
