HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine
Specifications
Brand Name :
CLW
Model Number :
CLW50091
Certification :
CCC,ISO,BV,SGS
Place of Origin :
Suizhou,China
MOQ :
1 UNIT
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
30-35days after received advance payments
Packaging Details :
Naked packing
Truck Brand :
HOWO
Engine :
Cummins, 168 HP
Wheelbase :
4500 mm
Gearbox :
6 forwards & 1 reverse
Crane :
5Ton XCMG Telescoping Boom Crane
Color :
Customized LOGO painting as per customer request
Crane Brand :
SANY,XCMG,CHENGLI And Other Chinese Brand
Rotation angle :
360°All rotation
Description

HOWO 4x2 Cummins 168HP 5Ton Telescoping Boom Crane Hydraulic Truck Mounted Crane

Product Description

  • Crane Brand of truck mounted straight arm crane: XCMG, SANY PALFINGER, Other Chinese Brand
  • Heavy Duty Cargo box.
  • H Shape Hydraulic front & Rear Leg for safety.
  • Folded Arm & Telescopic Straight Arm Crane for option.
  • Crane capacity of truck mounted straight arm crane:2ton,2.5ton,3.2ton,4ton,5ton,6.3ton,8ton,10ton,12ton,
  • 14ton,16ton,20ton,25ton

Chassis
Drive Model 4x2, Left hand drive
Vehicle Main Dimensions Dimensions(L x W x H)(mm) 8215*2500*3850
Wheel base (mm) 4500
Weight in KGS Curb Weight (kg) 8450
Gross weight(kg) 15795
Front/Rear axle loading(kg) 2700/7200
Max. driving speed(km/h) 90
Engine Horse Power(HP) Cummins, 168HP
Emission standard Euro II
Gearbox 6 forwards & 1 reverse
Steering Gear Power steering, hydraulic steering with power assistance
Brakes Air Brake
Tire 10.00-20 tire, 10pcs with 1 spare tire
Upper Cargo
Material Q235B
Dimension 5070X2400X600mm
Thickness 3mm for side /4 mm for the bottom
Technical parameter of crane
Crane Model 5Ton 4 Arms Knuckle Boom Crane
Crane Weight 2260kg
Max. Lifting capacity 5000kg
Max lifting height 12M
Working radius 11M
Max. Oil flow of hydraulic system 32L/min
Max. Pressure of Hydraulic system 20MPa
Oil tank capacity 90L
Installation space 900 mm
Rotation angle 360 degree All rotation
Remarks 1.Color is optional
2.Customized LOGO painting as per customer request

Product details

HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine

HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine

Technical Drawing:

HOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP EngineHOWO 4x2 5 Ton Hydraulic Truck Mounted Crane With Cummins 168HP Engine

Sales Service

①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of truck mounted straight arm crane I can order from your company?


A: There are various sizes and types of Truck Mounted Knuckle Boom Cranes with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2:: Have you supplied truck mounted straight arm crane to any overseas companies?


A: Yes,with need of equipment lifting,we offered crane trucks to many Africa and south-east Asian countries.

Q3 What about warranty?


A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?


A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
