Specifications
Brand Name :
CLW
Model Number :
CLW5208
Certification :
CCC,SGS,BV
Place of Origin :
SUIZHOU,CHINA
MOQ :
1 Unit
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 UNITS/MONTH
Delivery Time :
30 days after receiving deposit
Packaging Details :
naked,waxed,bulk ship,ro-ro
Truck Chassis :
Dongfeng,Howo,ISUZU,Shacman,CAMC,Foton
Capacity :
8t,8ton,8tons,9t,9ton,9tons
Type :
water tank fire truck,foam,dry powder fire truck,rescue fire truck
Fire Pump :
Chinese brand
Fire monitor range :
≥50M
Flow rate of monitor :
48L/s
Flow rate of pump :
60L/s
Steering :
LHD or RHD
Description

Rescue Fire Truck howo 4X2 emergency fire fighting truck with 5tons crane

Product Description

1.rescue fire truck is composed with truck body and cabin,cabin is two rows,which can allow 6 persons.The front part of truck body is equipment room,middle is water tank and foam tank,rear is pump room.

2) To ensure good performance of fire trucks,rescue fire truck is equipped with middle and low pressure fire pump CB20.10/30.6o with flow rate at 60L/S and Chengdu Wester fire monitor PL48(PM160)or PS60W(SG160).

3) rescue fire trucks are widely used in factory,terminal,oil&gas depot to insure emergency fire cases.

Specifications of howo rescue fire truck

Item Unit Parameter
Overall dimensions mm 9135x2500x3600
GVW kg 19850
Curb weight 11890
Water tanker L 6000
Wheel base mm 4600
F/R track base 2022/1830
Approach/departure angle ° 14/14
Exhaust/hp ml/kw 9726/247
Horse power 336hp
Max speed km/h 85
Tire specification 12R22.5,6pcs with one spare
Engine Model WD615.69 Emission standard Euro II
Cabin left hand drive,2+4
Equipment

◆ Water Tank 6000L and foam 2000L

◆Fire pump:CB20.10/30.60 flow: 60L/s

diversion time≤50s (Pressure: 1.0Mpa)
◆Fire monitor: PL48-64D flow: 48-64L/s range: water≥60m (Pressure: 1.0Mpa-1.2Mpa)

◆Power takeoff.

Rescue System:

1) Lifting light system

Main light:4X1000W

Lifting height:7.6M

Gas pump:AC220V

Electric control box:AC380V wired remote contol

2) Hydraulic crane system

Max. lifting capacity:5000kg

Max. lifting torque:6ton.m

Max. working range:5.8M

Max. lifting height:7.4M

Max. span of landing legs:3540m.m

3) Front electric winch

Voltage:24VDC electric current:240A

pulling capacity:8000khf(3629kg)

speed:5.6m/min

4) Generator:

Voltage:380V

Power:10KV/A

Powered by electrically or manually

Rescue Fire Brigade Truck Howo 4 X 2 Emergency Fire Fighting Truck With 5 Tons Crane
Rescue Fire Brigade Truck Howo 4 X 2 Emergency Fire Fighting Truck With 5 Tons Crane
Rescue Fire Brigade Truck Howo 4 X 2 Emergency Fire Fighting Truck With 5 Tons Crane

Our Service

  • Quick feedback to solve your questions

  • Professional engineering and production team

  • Related Accessories and spare parts offered,no future worries

  • Regular customer after-sale visiting

  • Free technical staff training and guidance

  • Reasonable price and good quality

  • Quick delivery and shipment

FAQ

Q1: What kinds of rescue fire truck I can order from your company?


A: There are various sizes and types of fire fighting trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2:: Have you supplied rescue fire truck to any overseas companies?


A: Yes,with need of government project,we offered fire fighting trucks to many Africa and south-east Asian,south-American countries.

Q3 What about warranty?


A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?


A: Our factory is based in Suizhou city, Hubei province, China. Our overseas marketing office is in Wuhan city,Hubei Province.Wuhan is about two hours' plane and four hours' high speed train from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
