Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck
Specifications
Brand Name :
CLW
Model Number :
CLW5417HS
Certification :
CCC ISO ASME
Place of Origin :
Suizhou,China
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 units/month
Delivery Time :
30 days after received advance payments
Packaging Details :
Naked package shipped by bulk ship
Driving model :
LHD&RHD
Chassis Brand :
HOWO, Dongfeng, Foton, Shacman, Isuzu Compactor garbage truck
Fuel Type :
Diesel engine garbage truck
Material :
carbon steel
Volume :
7m3, 7000liters, 7cbm, 4tonns,4mt
After-sales service provided :
Overseas third-party support available, Online support, Video technical support, Free spare parts, Field maintenance and repair service
Truck type :
Compactor Rear Loader Recycling Roll, Garbage Compressor, Garbage Compactor
Name :
Compactor GarbageTruck, new refuse compactor trucks, garbage compactor truck for sale, garbage compactor recycling truck
Loading Capacity :
3tons, 4tons, 5tons, 3t, 4t, 5t
Wheel Base :
3380
Description

Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck

Product Description

  • Widely used, support customized

  • Heavy load , simple operation

  • Plate thickening , fully function

  • High-quality Q345 manganese steel of WISCO, with three sides and four bottoms, curved box body, which has good force, no deformation, and larger loading capacity.

  • Box body adopts automatic welding (full welding), which does not scrape dust, does not leak, beautiful and durable.

  • Double sewage collection tank design, sealed treatment, eliminate secondary pollution, sewage tank is installed with a unique sewage valve, reliable sealing, not easy to block.

Specification of 7cbm 6 Wheel Compressed Garbage Truck

Specification of Truck Chassis
Driving Model 6X4
Cab Dongfeng cabin,left/Right hand drive, single row,2~3 passengers, with air conditioner
Wheel Base 3380mm
Loading Weight 6300kg
Curb Weight 2750kg
Axle Loading (front/rear) 3620/5430 kg
External Dimensions (L x W x H) 6815×2030×2350mm
Overhang (front/rear) 1115/1900mm
Wheel track (front/rear) 1670 /1586mm
Approach/Departure angle 20°/ 16°
Max. driving speed 99 km/h




Engine		 Model YUNNEI engine,YN38PE-2
Type 6-cylinders in a line, turbo-charging and inter-cooling
Horse Power 122Hp
Emission standard Euro3
Displacement 3760ml
Gearbox Manual type,8 forwards & 1 reverse
Clutch Reinforced diaphragm clutch
Tire 8.25R16 14PR, 6 pieces with 1 spare tire.
Garbage Truck Body
Tanker body material Quality high tensile Q345 carbon steel
Shape rectangular box, arc-shaped rear
Thickness Side 3mm, Bottom 4mm
Garbage Container Size 7 CBM,7000liters
Max. Loading Capacity 70~80 Barrel (240L)
Pressing system
Pressure 16Mpa
Compaction ratio 1.2:1
Loading cycle 25-30 second
Unloading cycle 15-20 second

pressing mechanism		 The giving plate and hinge related pressing plate moving on two directing
bars
Pressing mode Automatic pressing
Control of pressing Control from the external panel on the bunker

Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck

Euro3 7cbm/7m3 Rubbish Removal Truck 6 Wheel Compressed Garbage Truck

FAQ

Q1: What kinds of garbage trucks I can order from your company?


A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2:: Have you supplied garbage truck to any overseas companies?


A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.

Q3 What about warranty of garbage truck?


A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q4: Where is your factory? How far from Shanghai to your factory?


A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
