ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
Specifications
Brand Name :
CLW
Model Number :
CLW5064
Certification :
CCC,ISO,BV,SGS
Place of Origin :
Suizhou,China
MOQ :
1 UNIT
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
30-35days after received advance payments
Packaging Details :
Naked packing,Ro-ro,Bulk Ship
Truck Chassis :
ISUZU,Dongfeng,Foton,Shacman,JAC,JMC,FAW,HOWO
Tank Material :
Carbon steel Q235A
Water Tank :
2CBM/2000liters
Dust Tank :
3CBM/3000liters
Vacuum pump :
Chinese or Italy brand for choice
Wheelbase :
3360 mm
Color :
Customized LOGO
Warranty :
One year for major parts
Operation video :
Yes
User manual :
yes
Description

UZU 5cbm Sewage Vacuum Truck 5tons Sewer Cleaning Truck

Product Description

1. Purpose: It used for city and factory sewer cleaning, it's one of our sanitation truck series. Our mission is assist urban sanitation project and make world cleaning!

2. Main parts: Water pump and High pressure water cleaning nozzles tc.

3. Features: It can adopts high pressure water for flushing sewer.

4.5000 liters sewage vacuum suction truck with 2000 liters high pressure water tank(1000 liters by eash side)

Vehicle Description
Overall dimensions 5995*2250*3250 mm
Curb Weight 5400kg
Chassis brand ISUZU
Traction type 4*2
Tanker Description
Tanker Capacity 5000L
Material 6mm thickness, high quality carbon steel
Structure Welding, vacuum tank, Cylindrical
Pump Type Double vacuum pump
Flux 68(L/S)
Rating speed 800~1000(r/min)
Shaft power 5(kw)
Features Low speed, low fuel consumption, low noise, high vacuum, high efficiency
Manufacture Hangzhou WEILONG Pump Co., Ltd.
Pipe Suction and discharge pipe
Special function Suction time ≤ 5mins,
effective suction range ≥ 8,
Max vacuum degree ≤ 15 Kpa,
dump angle ≥ 45
Standard configuration Equipped with Inspect window,discharge valve,cleaning apparatus,5 meter long suction pipe,oil-water separators, overflow valve,etc.
Cylinder vacuum tank can be lifted hydraulically to
40-45 degree. Rear door can be opened and closed hydraulically.
Optional configuration Tanker material: stainless steel.
Vacuum pump : Italy or Spain vacuum pumps.
Anti-rust coating inside tank
Chassis Description
Chassis model ISUZU
Cab Sleeper cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension, adjustable driver's seat, air conditioning system, electric windows, central lock.
Traction type LHD or RHD
Drive type 4*2
Wheelbase 3360mm
Tire specification 8.25-16
Tire quantity 6+1 units
Engine Emission level Euro 1/2/3/4
Displacement/output 2771ml
Horse power 95hp
Gear box Model China famous brand
Number of gears 5 forward gears& 1 reverse, synchronized
Brake system Full air brake system, split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake
Axle Front 2.5T
Rear 4T
Truck details:
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A TankISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank​IS
ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A TankISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank
Accessories

ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank

Working Process

​ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank

ISUZU 4x2 5cbm Sewage Vacuum Truck With Q235A Tank

Sales Service

1. Professional engineer team with more than 20 years experience, technical support whenever needed.

2. Our team will take operation videos to show you how to use the truck step by step, it will be very easy for first learners.

3. Live video guidance about usage and maintenance.

4. Life long service whenever needed

FAQ

Q1: What size Sewage Suction tank we can get from your company?

A: we can supply 5CBM to 35CBM sewer cleaning truck as per our customer's request. Pls contact with us for more technical details discussion.

Q2: What is your production standard of Mobile Advertisement Truck products? Whether your Mobile Advertisement Truck can export to USA, Canada and Europen countries?

A: Our CBU Sewer cleaning truck is produced as per China GB local standard; We can export super structure to those market, we ever exported 50 units sewage suction truck's super structure and 20 units sewage suction sewage trailer to Australia market in the past two years.

Q3: Can we adopts International brand sewage pump for sewage suction truck?

A: Sure, we already cooperated with Italy Jourp and a Germany brand.

Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
