Specifications
Brand Name :
TYM
Model Number :
TYM4545
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
»1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 set year
Delivery Time :
45 workdays
Packaging Details :
wooden case
Injection rate :
30g/s
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas,Online support
Automatic :
Yes
Clamping force :
130T
Machine dimension(l*w*h) :
2.4*1.6*3.4m
Product name :
Liquid Injection Molding Machine LSR Injection Molding Machine Manufacturers
Warranty :
1 year
Description

Liquid Injection Molding Machine LSR Injection Molding Machine Manufacturers

The main feature of the horizontal Liquid Injection Molding Machine :
1. Newly-optimized integrated all-in-one design.
2. Meet multiple requirements on the automatic manufacturing technique for LSR products.
3. Shorter the mould closing and opening time, improve the production efficiency.
4. Remote control function.
5. Multi-section mould closing and opening and injection, speed adjusting stepless.

Green High Speed Injection Moulding Machine , Durable Low Pressure Injection Molding Equipment

Machine Model Parameter

Machine Model Shot Volume Injection Rate Injection Pressure Clamping Force

Opening Stroke

Tie-Bars Force Ejection Force Ejection Stroke Pump Pressure Machine Weight Motor Power Machine Dimension
TYM-W4545 148g 30g/s 700kg/cm2 130T 200-700mm 450*450mm 4.3T 150mm 21Mpa 5.2T 12.1KW 4.0*1.2*1.9m
TYM-W5050 270g 30g/s 700kg/cm2 150T 200-700mm 500*500mm 4.3T 150mm 21Mpa 5.3T 12.1KW 4.2*1.4*1.9m
TYM-W5555 270g 30g/s 700kg/cm2 160T 200-700mm 550*550mm 4.3T 150mm 21Mpa 5.6T 12.1KW 4.5*1.6*2.0m

Green High Speed Injection Moulding Machine , Durable Low Pressure Injection Molding Equipment

Machine Prduct Scope:
1) Liquid silicone medical part, as like the capsule, laryngeal mask capsule, oxygen mask, protective mast, catheter, balloon, medical belt etc.
2) Silicone auto parts, silicone valve, O-ring, sealing part.
3) Electronics and industrial product, such as the watchband, mobile phone case.
4) Sex products, such as the vibrating spear, sex toy coat, adult supplies etc.
5) LSR products, which can be with the insert, as like the plastic part, steel part etc. As sample: silicone diving mask, electric silicone drum Stick, silicone handle, silicone vibrators etc.

Green High Speed Injection Moulding Machine , Durable Low Pressure Injection Molding Equipment

Green High Speed Injection Moulding Machine , Durable Low Pressure Injection Molding Equipment

Our Service & Advantages:
1. Reply your enquiry in 24 working hours.
2. More than 17 years experience to LSR injection molding machine in China.
3. Tianyuan can design the LSR injection molding equipment according to the customer's requirements, provide a whole set of solutions for the LSR equipments.
4. Our LSR injection molding machine is widely used in medical industry, food industry, infant industry , diving industry, insulator industry and other LSR production field.
5. According to the high quality, precise and reliable of the LSR injection molding machine, we help the customer to produce the refined LSR products and price ratio is in high performance in the LSR industry.
6. Welcome OEM and ODM.
