Specifications
Brand Name :
Rui-He
Model Number :
RH625-0212-5
Certification :
RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001
Place of Origin :
GuangZhou, China
MOQ :
100KG
Price :
USD $+3-7/PER Kilograms
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1200 tons per month
Delivery Time :
5-8days
Packaging Details :
20kg pails OR 200Kg / drums
Ratio :
1:1
Liquid silicone rubber :
liquid silicone
Certificate :
RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001.
Performance :
great temperature range capabilities
Physical form :
Liquid silicone rubber
R & D Center :
30 persons
Application :
Industrial
shelflife :
within 400 days
Feature :
Safety And Environmental Protection
Design :
Customized as requested
Description

Injection molding of liquid silicone rubber LSR Manufacture China two-part platinum-cured elastomer

LSR is platinum-cured and natural transparent silicone which is more transparent than solid silicone. Liquid silicone rubber can mixed with pigmentation to produce colorful LSR molded products.

The silicone products we supply include liquid silicone rubber and room temperature vulcanizing silicones.

The products are transformed into silicone elastomers through the process of vulcanization.

Our silicone rubber products deliver excellent performance in the silicone engineering range of products

Product description

Silicone rubber molding is accomplished in five different ways:

1. cast molding,

2. injection molding,

3. compression molding,

4. transfer molding

5. dip molding

Ruihe RH6250 SERIES Liquid Silicone Rubber (F-LSR) is specifically designed for liquid injection molding.

The product is supplied as a two component, soft fluorosilicone paste. It heat cures to a 60 durometer material.

The cured rubber product is resistant to a wide variety of solvents and chemicals over a wide temperature range

of -63 to +175°C (-82° to +347°F) under immersion conditions, and up to +225°C (+437°F) in dry heat.

Injection Molding Of Liquid Silicone Rubber Two - Part Platinum - Cured Elastomer

Application

These grades are particularly suitable for the economical production of large series of injectionmoulded articles.

Parts made from RUI-HE RH6250-50 can be used for technical and pharmaceutical applications.

These articles are also suitable for use in conjunction with foodstuffs.
Injection Molding Of Liquid Silicone Rubber Two - Part Platinum - Cured Elastomer
Processing
Mixing
Rui-he RH 6250 series Liquid Silicone Rubber is a two-component material supplied as parts A and B,
which should be combined in a 1:1 ratio. Meter mix equipment which pumps, meters, and mixes
the two components without the incorporation of air is strongly recommended for production.
Pot Life
After the A and B components are mixed, Liquid Silicone Rubber will remain usable for at least 48 hours at room temperature.
Injection Molding Of Liquid Silicone Rubber Two - Part Platinum - Cured Elastomer
Storage
The 'Best use before end' date of each batch is shown on the product label.
Storage beyond the date specified on the label does not necessarily mean that the product is no longer usable.
In this case however, the properties required for the intended use must be checked for quality assurance reasons.
Physical properties Testing method Unit RH6250-40A/B RH6250-50A/B RH6250-60A/B RH6250-70A/B RH6250-71A/B
Appearance Visual inspection / Transparent
Viscosity DIN53019 Pa.s 1200 1200 1500 2000 2500/
Hardness GB/T 531.1 Shore A 40 50 60 65 70
Density

GB/T

533

 g/cm3 1.11 1.12 1.12 1.13 1.13
Resilience

GB/T

1681

 % 55 65 60 55 55
Tensile Strength GB/T 528-2009 Mpa 7.5 9 9.5 9.5 9
Elongation GB/T 528 % 550 550 500 400 350
Tear Strength GB/T 529 KN/m 25 30 35 30 25
Tensile Set GB/T 528 % 2.6 1.7 1.7 0.8 0.8
Linear shrinkage CGB-T14235.4 % 2.5 2.6 2.6 2.5 2.5

Injection Molding Of Liquid Silicone Rubber Two - Part Platinum - Cured Elastomer

Injection Molding Of Liquid Silicone Rubber Two - Part Platinum - Cured Elastomer
CONTACT US
For more than 15 years, OEM designers and maintenance and materials engineers around the world have trusted
the Rui-he brand for performance and expertise to solve or prevent sealant challenges.
Rui-he has sales offices, manufacturing sites, and science and technology laboratories – and a network of more than 200.
To learn more about our extensive product and service offerings, order samples, visit lsrliquidsiliconerubber.com
email: chenp8008@@gmail.com or call at(wechat//whatsapp) +86 136 6016 5505.
