PCB or PCB Assembly files requests
1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly
To short the lead time, please kindly advise us if there is any acceptable components substitution.
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary
2. Capability -PCB
1).Number of Layer: 2-28Layer
Maximum processing area: 680 x 1000 mm
Min board Thickness:
2 Layer 0.3mm(12mil); 4 Layer 0.4mm(16mil);
6 Layer 0.8mm(32mil); 8 Layer 1.0mm(40mil);
10 Layer 1.1mm(44mil); 12 Layer 1.3mm(52mil);
14 Layer 1.5mm(59mil); 16Layer 1.6mm(63mil);
18 Layer 1.8mm(71mil);
Finished board thickness tolerance:
Thickness<0.8mm,Tolerance:+/-0.08mm;
0.8mm≤Thickness≤6.5mm,Tolerance+/-10%
3. Min trace/gap(mm): 0.1mm
4. Min diameter of finished hole: 0.1mm (Normal hole is 0.2mm, but should base on you borad thickness.)
5. for E-Test
1) Universal Tester
2) Flying Probe Open/Short Tester
3)High power Microscope
4) Solder ability Testing Kit
5)Peel Strength tester
6)High Volt Open & Short tester
7)Cross Section Molding Kit With Polisher
