36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design
Specifications
Brand Name :
Luxtronic
Model Number :
TP-20W
Certification :
IEC/CE/ROHS
Place of Origin :
China
Payment Terms :
T/T, L/C
Supply Ability :
10000/month
Delivery Time :
4-6 weeks
Packaging Details :
9pcs/710*280*250mm/ctn
Item Type :
LED Tri-proof Light
Input Voltage :
AC220-240V 50/60Hz
Power :
20W
LED chips :
China 2835 chips
CCT :
4000K/5000K/6500K
CRI :
80
Power Factor :
>0.95
Working Temp. :
-20℃~+35℃
Materials :
PC
Warranty :
3 Years
Price :
Negotiable
Description

New arrival Warehouse lighting IP66 waterproof 36W LED Tri-proof light Linear fixture

Advantage of our triproof led light:

1. High brightness led chip: SMD 2835, with 130lm/w.

2. Isolated constant current led driver,the light work stably.

3. Special design, easy installation.

4. Emergency, dimmable, dali dimmable, motion sensor funtion are available.

5. IP66 triproof.

Product Description

Item Power

LED Qty

(110LM/W)

LED Qty

(130LM/W)

 Material Chips

Product Size

(MM)

CTN/Qty

(Pcs)

 CTN/Size(MM)
TP-20W-650 20W 48Pcs 102Pcs PC/PC 201 Stinaless 660×100×83 9 685X280X334
TP-20W-1220 20W 48Pcs 102Pcs PC/PC 201 Stinaless 1230X100X83 6 1255X280X225
TP-36W-1220 36W 90Pcs 192Pcs PC/PC 201 Stinaless 1230X100X83 6 1255X280X225
TP-36W-1560 36W 90Pcs 192Pcs PC/PC 201 Stinaless 1570X100X83 6 1595X280X225
TP-54W-1560 54W 138Pcs 288Pcs PC/PC 201 Stinaless 1570X100X83 6 1595X280X225

Product Details

36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design

36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design

36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design

Product Installation

1.Check all the parts and accessories of Linear LED light;


2.Must cut off the power supply before installation;


3.Make sure the light is fixed tightly to the surface of place for installation;


4.Connect the power line of light with power supply, then switch on the power.


5.When the Linear highbay light is working, it must be kept vertical downward.

36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design

Product Applications

---Instead of the fluorescent lights indoors


---School / Universities / Hospital


---Conference / Meeting room / Show Room


---Commercial establishments


---Factories / Offices

36W Led Warehouse Lighting IP66 Triproof 130lm/W SMD 2835 Special Design

Our Service

1. For all your inquires about us or our products, we will reply you in detail within 24 hours;

2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language;

3. We offer OEM services. Can print your own logo on product , can customize the retail box packing and other things.

4. We have very experienced R&D engineers and we have strong ability to do OEM projects.

Please feel free to contact me once you wanna know more !
