Travel Height ≤8000MM Heavy Duty Escalator With Step Loss Protection Device
Travel Height ≤8000MM Heavy Duty Escalator With Step Loss Protection Device
Specifications
Brand Name :
WELLIFT
Model Number :
W8
Certification :
Special Equipment Type-examination Certificate
Place of Origin :
China
MOQ :
One Unit
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
1000 Unit per month
Delivery Time :
40 work days
Packaging Details :
Export package
Product Name :
Heavy Duty Escalator
Type :
Outdoor
Usage :
Subway, Airports, shopping mall, etc
Function :
Basic+ Optional
Step width :
600mm/ 800mm / 1000mm
Speed :
0.5m/s
Travel height :
H≤8000mm
Balustrade :
GLASS OR ST.ST.
Display Type :
Interrupted or Parallel arrangement
HS Code :
8428400000
Description

More Safety Transport Heavy Duty Escalator with Step Loss Protection Device

Step loss protection device is the one standard function of escalator. It sets one monitor device respectively in drive station and steering station. When it detects step or tread loss, escalator immediately stops. It thus effectively ensures the passengers' safety.

WELLIFT automatic escalator sets a series of safety protection device. Our public transport escalator with multiple safety protection, VVVF drive, high-performance traction machine, and it support 30° and 35° Inclination. WELLIFT indoor escalator and outdoor escalator make the passengers feel comfortable, smooth and very secure. It is applicable for Subway, Airports, hotels, office buildings, shopping center, etc with good quality and competitive price.

Outdoor escalator has the same configuration and functions as indoor escalator. Considering the use environment of outdoor escalator, WELLIFT W8 serial outdoor escalators have added the following features:

  • Anti-rusting and anticorrosion treatment

Truss applies superior profile steel with unique structure, high intensity, thorough anti-rusting and anticorrosion treatment, fine effect, long life.

Conveyor chains proceed with special heat treatment (surface is nickel-plated)

Upper and lower part of the escalator structure should be protected by anti-rust and marine paint.

  • Water-proof measures

The whole design takes the escalator drainage system into consideration. Drive motor adopt water-proof type. Main and secondary step chain sprockets all use Germany water-resisting materials. Bearing is sealed and water-proof. So ensure steps work normally in outdoor environment.

  • Insulation Measures

Adopts Germany sealed safety switches.

Wires and switches are connected by special designed fastening cover.

All wires adopt elevator cables and wiring in sealed insulating box.

Set up special ground connecting device with control cabin.

  • Dust-proof functions

Steps and front plates with skid-proof function

  • High insulating level

Outdoor escalator electric device insulating level is up to IP44

  • Traction machine abandon belt brake, use center brake instead.
  • Set up oil-water separator equipment

WELLIFT W8 serial escalator has unbeatable advantages on safety, operation appearance and energy saving in this trade. It is applicable for hotels, office buildings, shopping center, etc with good quality and competitive price.

Standard Specification of W8 serial outdoor escalator

Target market: Shopping mall, Commercial Building, Hospital, Subway, Airports
Step width 600mm, 800mm, 1000mm
Speed(m/s) ≤0.5
Inclination 30°, 35°
Max. Vertical rise ≤8000mm
Operating environment outdoor

Superior Performance of W8 serial escalator

Safety
“Safety the first" is the basic guideline of W8. The design, manufacture and installation all reach or exceed GB16899-2011 and EN115 "Safety rules for the construction and installation of escalators and passenger conveyors”.
Reliability
1 W8 runs smoothly, comfortable and safe to take. It is the perfect combination of ideal design solution and up-to-date technical achievement
2

The truss are made of special bar sections and rectangle steel tube, with stress relieving treatment,

so that to be solid, durable and no deformable
3 The drive device adopts the most advanced technology of German FRANDER Company which has the features of high efficiency uniform operation and low noise
4 The control system adopts Japanese new-generation PLC technology, which can perform function setting and trouble self-diagnose, the remote monitoring interface can be added if necessary
5 The steps which formed from High-strength whole piece die-cast aluminum or stainless steel, and high-quality handrail guarantee the handsome appearance, safety and durability of escalator.
6 Following ISO9001 Quality Control System, each W8 escalator is manufactured and tested carefully to be of good quality
New Standard Configurations
  • Automatic oil lubricator
  • Automatic trouble display
  • Remote monitoring interface
Optional Function
  • Automatic start / stop System
  • VF drive system
  • Oil / water separator(Apply to outdoor escalator)
Decorative Selection
  • With elegant appearance, advanced technology and smart design, W8 is harmonious with various circumstances. You can select suitable handrail glass and tread according to building style
  • Standard color of handrail is black; other 4 colors (blue, green, and grey, red) are available with additional charge.

WELLIFT W8 serial escalator has unbeatable advantages on safety, operation appearance and energy saving in this trade. It is applicable for hotels, office buildings, shopping center, etc with good quality and competitive price.

Please feel free to contact us if you have any need for our products. Also you can visit our company website www.wellift.com to download product catalogues.
