Specifications
Condition :
New
No. of Spindles :
Single
Type :
Horizontal
Weight (T) :
8 T
Table Size (mm) :
1300*600
CNC Control System :
GSK, FANUC, KND
Number of Axes :
3, 4, 5
Table Travel (X) (mm) :
1000
Table Travel (Y) (mm) :
750
Table Travel (Z) (mm) :
600
Positioning Accuracy (mm) :
0.008
Repeatability (X/Y/Z) (mm) :
0.005
Spindle Motor Power(kW) :
11
Max. Table Load(kg) :
800 kg
Min. Time of Tool Change(s) :
2
Tool Magazine Capacity :
16, 20, 24
Key Selling Points :
Automatic
Warranty :
1 Year
Place of Origin :
Shandong, China
Brand Name :
lu young
Voltage :
220V/380V
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
After-sales Service Provided :
Engineers available to service machinery overseas
Machine Type :
horizontal Machine Centers
Product name :
New Products Multifunction cnc milling machine 3 axis horizontal
Controlling Mode :
Cnc System
Product type :
cnc Machining Center
Processing :
Maching Center
Spindle speed :
10000 Rpm
Application :
Metal Machining
Control system :
KND SIEMENS GSK FANUC (optional)
After Warranty Service :
Online support
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Construction works
Showroom Location :
None
Core Components :
Other
Price :
$49,000.00/sets 1-1 sets
Description
horizontal milling machine Horizontal machining center HMC1075 working for metal car's hubs processing
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Specification
Description
HMC1075
HMC1290
HMC1395
HMC 1814
Worktable size(mm)
1300×600
1360×700/630*630 rotary table
1400×700/630×630 rotary table
2000×900/800*800 rotary table
Max loading weight on worktable( KG)
800
1000
1000
1600
T-slot（pieces-width-distance）(mm/piece)
5-18-105
5-18-122
5-18-130
5-22-165
X axis travel (mm)
1000
1200
1300
1800
Y axis travel (mm)
750
800/600
800
1280
Z axis travel (mm)
600
700
750
900
Distance from spindle end face to worktable center distance (mm)
115-715
180-880
168-918
200-1100
Distance from spindle center to worktable (mm)
110-860
140-940
260-1060/0-800
140-1420
Spindle taper (7:24)
BT 50 φ150
BT 50 φ190
BT 50 φ190
BT 50 φ190
Spindle speed (r/min)
6000
6000
6000
6000
Spindle motor (kW)
11
15
15
15
X axis Rapid feeding speed(m/min)
15
20
15
18
Y axis Rapid feeding speed (m/min)
12
12
12
12
Z axis Rapid feeding speed (m/min)
15
20
15
18
Feed speed (m/min)
1-10000
1-10000
1-10000
1-10000
Auto Tool changer design
arm type auto tool changer
Arm type auto tool changer
Arm type auto tool changer
Arm type auto tool changer
Auto Tool changer capacity (piece)
24
24
24
24
Tool changing time(tool-to-tool) s
2.5
2.5
2.5
2.5
Accuracy test standard
JISB6336-4：2000/ GB/T18400.4-2010
JISB6336-4：2000/ GB/T18400.4-2010
JISB6336-4：2000/ GB/T18400.4-2010
JISB6336-4：2000/ GB/T18400.4-2010
X/Y/Z axis accuracy (mm)
±0.008
±0.008
±0.008
±0.008
X/Y/Z axis Repeat positioning accuracy (mm)
±0.005
±0.005
±0.005
±0.005
Overall size（L×W×H）(mm)
3700×3050×2700
3750×3400×2900
3600×3400×2900
4800*3800*3450
Gross weight (kg)
8000
10000
10000
15000
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Product Description
horizontal milling machine Horizontal machining center HMC1075 working for metal car's hubs processing , X, Y, Z three-axis control, B-axis is arbitrary indexing, which can realize four-axis and four-linkage. The performance of the numerical control system is stable. The main motor is a servo motor. Through the control of the numerical control system, the workpiece can be processed for milling, boring, tapping, turning the outer circle, drilling and some complex curved surfaces. The tool magazine is equipped with an automatic tool change device, and the workpiece can be clamped to complete the rough and finish machining of various processes
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Product Feature
1. The horizontal milling machine Horizontal machining center HMC1075 working for metal car's hubs processing main components are optimized by finite element analysis, the main castiron is made of cast iron with stable metal log raphic structure, and the long-term accuracy of the machine tool is stable afteraging, sandblasting, tempering and other processes.
2. The machine tool adopts integral T-shaped casting bed, gantry column, positive hanging box head stock structure. Triangularreinforcing ribs are arranged inside the bed, and the structure of the bed is heavy, so that the machine tool can obtain high rigidity and stable precision.
3. High rigidity spindle unit combined with servo spindle motor; X/Y/Z adopts high torque servo motor.
4.X/Y/Z adopts Taiwan large diameter ball screw with Japanese NSK ball screw pair bearing and imported locking.
5. The X/Y/Z three-way guide rail adopts Taiwan HIWIN linear guide rail, which has high precision, fast wear and tear or
selects the hard rail design according to customer requirements.
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Company Profile
Luyang CNC machinery company has 20 years of production lathe experience, main CNC lathe, CNC milling machine, processing center,Swiss CNC lathe high-tech enterprise.The company has a professional production and development team and favorable after-salestechnical team support.The company takes the strength to make the product, the service wins the customer, the customer as thebasic management concept.Our company has gained a good reputation both at home and abroad by providing customers with
cost-effective CNC machine tools and excellent timely sales advice and after-sales service.Development, innovation,people-oriented, is the direction my company has been working on.
Our company continuously strengthen product performance improvements, innovation cost-effective CNC machinery, optimize productquality control system, to provide global support services as the dominant direction of the development of the company.
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
Packing & Delivery
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
Our service
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
♥Training how to instal the machine, training how to use the machine.
♥Engineers are available to service machinery overseas.
♥Provide tools and accessories.
♥Warranty is one year, we would offer the parts (quality problem) free of charge during this period.
♥Note: GSK, Servo driven, motor and transformer, warranty is 3 years.
Customer Photos
Online Support HMC1075 Horizontal Machining Center for Metal Car's Hubs Processing
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
.
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe
Machines ,MANUAL lathe Machine,Sawing Machine ,Shaper machine and so on .

3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province, China. You are warmly welcomed to visit us.

4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.

5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .

5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
